65" Diagonal Class IFPG1 Gen 2 Series LED-backlit LCD display - interactive - with touchscreen (multi touch) / optional slot-in PC capability - 4K UHD (2160p) 3840 x 2160 - Direct LED
| Main Specifications | |
|---|---|
| Product Description | ViewSonic ViewBoard IFP65G1-2 IFPG1 Gen 2 Series - 65" LED-backlit LCD display - 4K - for interactive communication |
| Product Type | LED-backlit LCD flat panel display with touchscreen (multi touch) / optional slot-in PC capability |
| Diagonal Class | 65" |
| Commercial Use | Yes - interactive |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| Video Interface | HDMI |
| HDMI Ports Qty | 2 ports |
| Connectivity | LAN |
| PC Interface | USB-C |
| LCD Backlight Technology | Direct LED |
| Image Aspect Ratio | 16:9 |
| TV Tuner | No tuner |
| Speaker System | 2 speakers, subwoofer |
| USB | Yes |
| Included Accessories | Remote control, 2 x Touch pen (Passive pen) (VB-PEN-101), RS232 adapter, 4 x screws |
| Voltage | AC 100-240 V |
| Power Consumption Stand by | 0.5 watt |
| Dimensions (WxDxH) | 58.4 in x 3.4 in x 35.1 in |
| Weight | 80.91 lbs |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Diagonal Class | 65" |
| Commercial Use | Yes - interactive |
| Combined With | Touchscreen (multi touch) / optional slot-in PC capability |
| Series | IFPG1 Gen 2 Series |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Sensors | Light sensor |
| Video Interface | HDMI |
| HDMI Ports Qty | 2 ports |
| PC Interface | USB-C |
| Modes | Landscape mode |
| Width | 58.4 in |
| Depth | 3.4 in |
| Height | 35.1 in |
| Weight | 80.91 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | 2 x Touch pen (Passive pen) (VB-PEN-101), RS232 adapter, 4 x screws |
| Cables Included | USB touch cable - 10 ft ¦ HDMI cable - 10 ft ¦ USB-C cable - 6 ft |
| Compliant Standards | HDCP 2.3, RoHS |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V |
| Power Consumption Stand by | 0.5 watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 80% (non-condensing) |
| Display | |
| Color Support | 1070000000 colors |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Image Aspect Ratio | 16:9 |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| LCD Backlight Technology | Direct LED |
| Coating | Anti-glare, 9H Hard |
| Image Contrast Ratio | 1500:1 |
| Dynamic Contrast Ratio | 5000:1 |
| Brightness | 400 cd/m² |
| Viewing Angle | 178° |
| Viewing Angle (Vertical) | 178° |
| Touchpoints Qty | 50 |
| Response Time | 8 ms |
| Backlight Life | 50,000 hours |
| Additional Features | 8-bit+FRC, Open Pluggable Specification slot |
| Connections | |
| Connector Type | 2 x HDMI input ¦ Audio input ¦ Audio output ¦ RS-232 input ¦ Gigabit LAN ¦ 2 x USB 3.2 Gen 1 - rear ¦ USB 2.0 - rear ¦ USB-C 3.2 Gen 1 with DisplayPort 1.2, touchscreen, 100W Power Delivery - rear ¦ USB 2.0 (for software update only) - rear |
| Remote Control | |
| Type | Remote control |
| Battery Form Factor | AAA type |
| Battery Included | Yes |
| Audio System | |
| Speaker System | 2 speakers, subwoofer |
| Output Power / Total | 40 watt |
| Speakers | 2 x main channel speaker - 10 watt ¦ 1 x subwoofer - 20 watt |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 64.6 in |
| Depth (Shipping) | 7.3 in |
| Height (Shipping) | 39.8 in |
| Weight (Shipping) | 96.34 lbs |
| Network & Internet Multimedia | |
| Connectivity | LAN |
| LAN Protocol | Gigabit Ethernet |
| Stands & Mounts | |
| Flat Panel Mount Interface | 600 x 400 mm |
| VESA Compatibility | Yes |
| Media Player | |
| USB Port | Yes |
| Configuration | ARM Cortex-A73 Dual-Core + ARM Cortex-A53 Dual-Core Mali-G52 MC1 |
