5G smartphone - dual-SIM - RAM 12 GB / Internal Memory 256 GB - OLED display - 6.9" - 6.9" - 2520 x 1080 pixels 2520 x 1080 pixels (120 Hz) - 2x rear cameras 50 MP, 12 MP - front camera 10 MP - graphite
| Main Specifications | |
|---|---|
| Product Description | Samsung Galaxy Z Flip8 - graphite - 5G smartphone - 256 GB - GSM |
| Product Type | 5G smartphone |
| Energy Label QR Code URL | Https://eprel.ec.europa.eu/qr/2610204 |
| Energy Class | Class A |
| EU Data Act | Https://dataact.samsung.com/#/public/notice-page?locale=en |
| Manufacturer Model Number | SM-F776U1 |
| Display | OLED display - 2520 x 1080 pixels - 6.9" - 400 ppi - (120 Hz) - Dynamic AMOLED 2X - Corning Gorilla Glass Victus 2 (scratch resistant glass) - inward - foldable |
| Display (2nd) | OLED display - color - 4.1" |
| Display (Unfolded) | 6.9 in - 2520 x 1080 pixels |
| Processor | Qualcomm Snapdragon 8 Elite Gen 5 for Galaxy 4.74 GHz (8-core) |
| Memory | RAM 12 GB / Internal Memory 256 GB |
| Operating System | Android 17 with One UI 9 |
| Main Camera | 50 Megapixel - wide-angle lens - f/1.8 - focus: automatic |
| Second Camera | 12 Megapixel - ultra wide-angle lens - f/2.2 |
| Front Camera | 10 Megapixel f/2.2 - focus free |
| Service Provider | Not specified |
| Form Factor | Folder (flip) - touch screen, dual screen |
| SIM Card | Dual-SIM - nano SIM, Electronic SIM card (e-SIM) |
| Wireless Interface | NFC, Wi-Fi 7, Bluetooth |
| Security Devices | Fingerprint reader |
| Connectors | USB-C |
| Wireless Charging Standards | WPC, Qi, Fast Wireless Charging, Wireless PowerShare |
| Protection | Water-resistant |
| Color | Graphite |
| Dimensions (WxDxH) | 3 in x 0.2 in x 6.6 in |
| Weight | 6.35 oz |
| Specific Absorption Rate (SAR) | 1.09 W/kg (head) ¦ 1.2 W/kg (body) ¦ 1.2 W/kg (wireless router) ¦ 1.59 W/kg (simultaneous) |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Product Type | Smartphone |
| Energy Label QR Code URL | Https://eprel.ec.europa.eu/qr/2610204 |
| Energy Class | Class A |
| Manufacturer Model Number | SM-F776U1 |
| EU Data Act | Https://dataact.samsung.com/#/public/notice-page?locale=en |
| Form Factor | Folder (flip) - touch screen, dual screen |
| Protection | Water-resistant |
| Width | 3 in |
| Depth | 0.2 in |
| Height | 6.6 in |
| Weight | 6.35 oz |
| Dimensions Details | Unfolded - 3 in x 0.2 in x 6.6 in ¦ Folded - 3 in x 0.5 in x 3.4 in |
| Body Color | Graphite |
| Body Material | Armor Aluminum frame, Corning Gorilla Glass Victus 2 |
| Memory | |
| RAM | 12 GB |
| Internal Memory Capacity | 256 GB |
| User Memory | 226 GB |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Regional Warranty Exceptions | Spain - 3 years |
| Miscellaneous | |
| Ingress Protection Rating | IP48 |
| Repeated Free Fall Reliability Class | Class A |
| Compliant Standards | IEC 61960, USB 3.2 Gen 1, Android Audio Streaming for Hearing Aid (ASHA), IP48 |
| Included Accessories | SIM card removal tool, USB-C to USB-C cable |
| Processor | |
| Type | Qualcomm Snapdragon 8 Elite Gen 5 for Galaxy |
| Clock Speed | 4.74 GHz |
| Processor Core Qty | 8-core |
| Environmental Parameters | |
| Max Depth of Water Resistance | 5 ft |
| Battery | |
| Technology | Lithium ion |
| Capacity | 4300 mAh |
| Fast Charging Technology | Qualcomm Quick Charge 2.0, Adaptive Fast Charging |
| Wireless Charging | Yes |
| Wireless Charging Standards | WPC, Qi, Fast Wireless Charging, Wireless PowerShare |
| Battery Endurance per Cycle | 2650 min |
| Battery Endurance in Cycles | 1200 |
| Run Time Details | Playback (wireless video): up to 31 hrs |
| Display | |
| Type | OLED display |
| Technology | Dynamic AMOLED 2X |
| Diagonal Size | 6.9" |
| Display Resolution | 2520 x 1080 pixels |
| Display Format | Full HD+ |
| Foldable | Yes |
| Design | Inward folding |
| Pixel Density | 400 ppi |
| Max Brightness | 2600 cd/m² |
| Color Depth | 16 million colors |
| Enhancement Technology | Vision Booster technology |
| Refresh Rate | 120 Hz |
| Protection | Corning Gorilla Glass Victus 2 (scratch resistant glass) |
| Features | 1-120Hz adaptive refresh rate, mobile Digital Natural Image engine (mDNIe) technology, FlexWindow, secondary screen: 342 PPI |
| Communications | |
| Data Transmission | FDD-LTE, TDD-LTE, 5G NR FR1 |
| 2G Band | 850 GSM, 900 GSM, 1800 GSM, 1900 GSM |
| 3G UMTS Band | Band 1, Band 2, Band 4, Band 5, Band 8 |
| 3G UMTS Frequency | 2100, 1900, 1700, 850, 900 |
| 4G LTE Band | Band 1, Band 2, Band 3, Band 4, Band 5, Band 7, Band 8, Band 12, Band 13, Band 14, Band 18, Band 19, Band 20, Band 25, Band 26, Band 28, Band 29, Band 30, Band 38, Band 39, Band 40, Band 41, Band 48, Band 66, Band 71 |
| 4G LTE Frequency | FDD 2100, FDD 1900 PCS, FDD 1800+, FDD 1700 - 2110 AWS, FDD 850, FDD 2600, FDD 900, FDD 700a, FDD 700c, FDD 700 PS, FDD 800 lower, FDD 800 upper, FDD 800 DD, FDD 1900+, FDD 850+, FDD 700 APT, FDD 700d, FDD 2300 WCS, TDD 2600, TDD 1900, TDD 2300, TDD 2500, TDD 3600, FDD 1700 - 2110 AWS-3, FDD 600 |
| 5G NR Band | N1, n2, n3, n5, n7, n8, n20, n28, n38, n41, n66, n71, n77, n78, n25, n12 |
| 5G NR Frequency | FDD 2100, FDD 1900PCS, FDD 1800, FDD 850, FDD 2600, FDD 900, FDD 800, FDD 700APT, TDD TD 2600, TDD TD 2500, FDD AWS-3, FDD 600, TDD TD 3700, TDD TD 3500, FDD 1900, n12 |
| Wireless Interface | NFC, IEEE 802.11a/b/g/n/ac/ax/be, Bluetooth 5.4 |
| Connections | |
| Connector Type | USB Type-C - 24 pin USB-C |
| Phone Features | |
| Sensors | Accelerometer, proximity sensor, barometer, gyro sensor, hall sensor, geomagnetic sensor, light sensor |
| Security Devices | Fingerprint reader |
| Additional Features | MIMO technology, Fast Charging, Samsung KNOX, Samsung DeX support, Samsung Smart Switch, dual stereo speakers, Samsung Knox Vault, Samsung Wallet, Galaxy AI, Photo Assist, Samsung Health, Samsung Care+, SmartThings Support, Quick Share, Now Brief, Armor FlexHinge, Samsung Knox Matrix Trust Chain technology |
| Cellular | |
| Technology | WCDMA (UMTS) / GSM |
| Mobile Broadband Generation | 5G |
| Service Provider | Not specified |
| Operating System | Android 17 |
| User Interface | One UI 9 |
| Intelligent Assistant | Google Gemini |
| Navigation | GPS, GLONASS, BeiDou, Galileo |
| SIM Card Type | Nano SIM, Electronic SIM card (e-SIM) |
| SIM Card Qty | Dual-SIM |
| Payment Technology | Samsung Pay |
| Input Device | Multi-touch |
| Display (2nd) | |
| Type | OLED display - color |
| Diagonal Size | 4.1" |
| Display Resolution | 1048 x 948 pixels |
| Color Depth | 16 million colors |
| Media Player | |
| Supported Digital Audio Standards | WAV, AAC, AMR, MP3, FLAC, XMF, OGG, MIDI, APE (Monkey's Audio), M4A, DSF, MXMF, OGA, 3GA, AWB, IMY, RTTTL, RTX, OTA, DFF, MID |
| Supported Digital Video Standards | MKV, FLV, AVI, 3GP, M4V, WebM, 3G2, MP4 |
| Front Camera | |
| Sensor Resolution | 10 Megapixel |
| Lens Aperture | F/2.2 |
| Focus Adjustment | Focus free |
| Field of View (FoV) | 85 degrees |
| Pixel Size | 1.12 ?m |
| Video Resolutions | 3840 x 2160 (4K) at 60 fps |
| Display (Unfolded) | |
| Diagonal Size | 6.9 in |
| Display Resolution | 2520 x 1080 pixels |
| Main Camera | |
| Sensor Resolution | 50 Megapixel |
| Optical Image Stabilizer | Optical Image Stabilizer (OIS) |
| Lens Type | Wide-angle lens |
| Lens Aperture | F/1.8 |
| Field of View (FoV) | 85 degrees |
| Pixel Size | 1 ?m |
| Focus Adjustment | Automatic |
| Digital Zoom | 10x |
| Camera Modes | Slow motion mode, Portrait, Night, Super Steady Mode, Dual Record, Flip Shot |
| Light Source | LED flash |
| Video Resolutions | Slo-mo video 1920 x 1080 (1080p) at 120 fps, 3840 x 2160 (4K) at 60 fps, Slo-mo video 1920 x 1080 (1080p) at 240 fps |
| Features | Dual Pixel Autofocus technology, Dual preview, FlexCam, ProVisual Engine, Photo Assist, 2x Optical Quality Zoom, Adaptive Pixel Sensor, Auto Zoom |
| Second Camera | |
| Sensor Resolution | 12 Megapixel |
| Lens Type | Ultra wide-angle lens |
| Lens Aperture | F/2.2 |
| Field of View (FoV) | 123 degrees |
| Pixel Size | 1.12 ?m |
| Sustainability Information | |
| Repairability Class | Class C |
| Product Recycled Content | 14.6 % |
