Without stand - LED monitor - 10.1" - touchscreen - 1280 x 800 Full HD @ 60 Hz - 400 cd/m² - 800:1 - 30 ms - HDMI, Mini DisplayPort - speakers - white
| Main Specifications | |
|---|---|
| Product Description | Elo 1004L - without stand - LED monitor - 10.1" |
| Device Type | LED-backlit LCD monitor - 10.1" - touchscreen |
| Energy Label QR Code URL | Https://eprel.ec.europa.eu/qr/2304938 |
| Energy Class | Class D |
| Features | Touchscreen |
| Aspect Ratio | 16:10 |
| Native Resolution | Full HD 1280 x 800 at 60 Hz |
| Brightness | 400 cd/m² |
| Contrast Ratio | 800:1 |
| Response Time | 30 ms (typical) |
| Color Support | 16.7 million colors |
| Input Connectors | HDMI, Mini DisplayPort |
| Screen Coating | Anti-glare |
| Color | White |
| Image Color Disclaimer | The displayed product image may be a different color |
| Dimensions (WxDxH) | 9.8 in x 1 in x 6.6 in |
| Weight | 31.74 oz |
| Compliant Standards | TUV Rheinland, AR, cUL, IC, CCC, Korea MEPS, KCC, BSMI, UKCA, UL, FCC, VCCI, PSE Mark, CB, RCM, Mexico NOM, RoHS, China RoHS, WEEE, REACH, BIS, AAMI ES60601-1:2005, AAMI ES60601-1:(R)2012, A1:2012, A1:(R)2012, A2:2021, EN 60601-1:2006, EN 60601-1:2006 + A1:2013, EN 60601-1:2006 + A12:2014, EN 60601-1:2006 + A2:2021, CAN/CSA C22.2 No. 60601-1:14, IP54, IK07 |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Display Type | LED-backlit LCD monitor / TFT active matrix |
| Energy Label QR Code URL | Https://eprel.ec.europa.eu/qr/2304938 |
| Energy Class | Class D |
| Diagonal Size | 10.1" |
| Aspect Ratio | 16:10 |
| Native Resolution | Full HD 1280 x 800 at 60 Hz |
| Brightness | 400 cd/m² |
| Brightness w/touchscreen | 360 cd/m² |
| Contrast Ratio | 800:1 |
| Color Support | 16.7 million colors |
| Response Time | 30 ms (typical) |
| Vertical Refresh Rate | 60 Hz |
| Horizontal Refresh Rate | 30 - 80 kHz |
| Horizontal Viewing Angle | 170 |
| Vertical Viewing Angle | 170 |
| Screen Coating | Anti-glare |
| Backlight Technology | LED backlight |
| OSD Languages | Chinese (traditional), Chinese (simplified), English, German, French, Italian, Spanish, Japanese |
| Features | Projected Capacitive Touch (P-CAP) technology, OSD lock, optical bonding, edge-to-edge glass, scratch-resistant |
| Color | White |
| Image Color Disclaimer | The displayed product image may be a different color |
| Dimensions (WxDxH) | 9.8 in x 1 in x 6.6 in |
| Weight | 31.74 oz |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | 2 cable ties |
| Cables Included | 1 x HDMI cable - 6 ft ¦ 1 x USB-A to USB-C cable - 6 ft |
| MTBF | 50,000 hour(s) |
| Compliant Standards | TUV Rheinland, AR, cUL, IC, CCC, Korea MEPS, KCC, BSMI, UKCA, UL, FCC, VCCI, PSE Mark, CB, RCM, Mexico NOM, RoHS, China RoHS, WEEE, REACH, BIS, AAMI ES60601-1:2005, AAMI ES60601-1:(R)2012, A1:2012, A1:(R)2012, A2:2021, EN 60601-1:2006, EN 60601-1:2006 + A1:2013, EN 60601-1:2006 + A12:2014, EN 60601-1:2006 + A2:2021, CAN/CSA C22.2 No. 60601-1:14, IP54, IK07 |
| Power | |
| Power Consumption SDR (On mode) | 7 kWh/1000h |
| Power Consumption (Typical) | 6.5 watt |
| Power Consumption Sleep | 1 watt |
| Power Consumption (Off Mode) | 0.25 watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 80% (non-condensing) |
| Audio | |
| Type | Speakers - stereo |
| Output Power / Channel | 2 watt |
| Connectivity | |
| Interfaces | USB-C with Power Delivery ¦ HDMI ¦ Mini DisplayPort ¦ 4 x Micro-USB |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 12.1 in |
| Shipping Depth | 5.6 in |
| Shipping Height | 8.8 in |
| Shipping Weight | 4.85 lbs |
| Input | |
| Type | Touchscreen - touchscreen |
| Movement Detection Technology | Projected capacitive |
| Mechanical | |
| VESA Mounting Interface | 75 x 75 mm |
