AI PC - tiny Core Ultra 7 265 / up to 5.3 GHz - vPro Enterprise - RAM 32 GB - SSD 1 TB - TCG Opal Encryption 2, NVMe - Intel Graphics - Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 - Win 11 Pro - monitor: none - keyboard: English - black - Lenovo TopSeller
| Main Specifications | |
|---|---|
| Product Description | Lenovo ThinkCentre M70q Gen 6 - tiny - AI PC - Core Ultra 7 265 - vPro Enterprise - 32 GB - SSD 1 TB - English |
| Type | Personal computer - tiny - AI PC |
| Platform Technology | Intel vPro Enterprise |
| Localization | Language: English / region: United States |
| Processor | Intel Core Ultra 7 (Series 2) 265 (up to 5.3 GHz, (20-core) |
| Processor Main Features | Intel Smart Cache |
| Neural Processor Unit (NPU) | Intel AI Boost - up to 13 TOPS |
| Cache Memory | 30 MB |
| Cache Per Processor | 30 MB |
| RAM | 32 GB (installed) / 64 GB (max) - DDR5 SDRAM |
| Hard Drive | SSD 1 TB - PCI Express 4.0 x4 - M.2 2280 - TCG Opal Encryption 2, NVM Express (NVMe) |
| Optical Storage | No optical drive |
| Graphics Controller | Intel Graphics shared video memory (UMA) - up to 8 TOPS |
| Networking | 1GbE, 802.11a, 802.11b/g/n, Wi-Fi 5, Wi-Fi 6E, Bluetooth 5.3 |
| Keyboard | English |
| Power | (50/60 Hz) |
| OS Provided | Windows 11 Pro |
| Color | Black |
| Dimensions (WxDxH) | 7 in x 7.2 in x 1.4 in |
| Weight | 2.6 lbs |
| Manufacturer Selling Program | Lenovo TopSeller |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | Limited warranty - 3 years - on-site |
| General | |
| Platform Technology | Intel vPro Enterprise |
| Type | Personal computer |
| AI Level | AI PC |
| Product Form Factor | Tiny |
| Built-in Devices | Speaker |
| Embedded Security | Discrete Trusted Platform Module (TPM 2.0) Security Chip |
| Color | Black |
| Localization | Language: English / region: United States |
| Expansion / Connectivity | |
| Slots | 2 (total) / 1 (free) x M.2 Card - 2280 (for SSD) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years - on-site |
| Miscellaneous | |
| Included Accessories | Vertical stand |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), chassis intrusion switch |
| Security Slot Type | Kensington security slot |
| Compliant Standards | RoHS, FIPS 140-2, TCG Certified, MIL-STD 810H |
| Manufacturer Selling Program | Lenovo TopSeller |
| RAM | |
| Installed Size | 32 GB (installed) / 64 GB (max) |
| Technology | DDR5 SDRAM |
| Rated Memory Speed | 5600 MT/s |
| Form Factor | SO-DIMM 262-pin |
| Slots | 2 (total) / 1 (empty) |
| Features | Dual channel memory architecture |
| Configuration Features | 1 x 32 GB |
| Networking | |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Wi-Fi 6E AX 211 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 |
| Features | Dual stream (2x2) |
| Power | |
| Device Type | Power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Provided | 135 watt |
| Efficiency | 90% |
| Cache Memory | |
| Installed Size | 30 MB |
| Cache Per Processor | 30 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel Graphics shared video memory (UMA) - up to 8 TOPS |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Operating System / Software | |
| OS Provided | Windows 11 Pro English |
| Hard Drive | |
| Type | SSD - M.2 2280 |
| Capacity | 1 x 1 TB |
| Interface Type | PCI Express 4.0 x4 |
| Features | TCG Opal Encryption 2, NVM Express (NVMe) |
| Input Device | |
| Type | Mouse, keyboard |
| Dimensions & Weight | |
| Width | 7 in |
| Depth | 7.2 in |
| Height | 1.4 in |
| Weight | 2.6 lbs |
| Keyboard | |
| Keyboard Name | Lenovo Traditional Keyboard |
| Interface | USB |
| Localization & Layout | English |
| Mouse | |
| Mouse Name | Lenovo Calliope Mouse |
| Interface | USB |
| Processor / Chipset | |
| CPU | Intel Core Ultra 7 (Series 2) 265 |
| Max Turbo Speed | 5.3 GHz |
| Number of Cores | 20-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Processor Main Features | Intel Smart Cache |
| Chipset Type | Intel Q870 |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 9.0 |
| Neural Processor Unit (NPU) | |
| Neural Processor Unit (NPU) | Intel AI Boost |
| NPU Performance Up To (TOPS) | 13 TOPS |
| Total Processor Performance Up To (TOPS) | 33 TOPS |
| AI Datatype Support on NPU | INT8 |
| Sparsity Support | Yes |
| AI Software Frameworks Supported by NPU | DirectML, OpenVINO, WebNN, WindowsML, ONNX RT |
| Windows Studio Effects Support | Yes |
