Multifunction printer - color - ink-jet - A3 (11.7 in x 16.5 in) (original) - A3/Ledger (media) - up to 100 ppm (printing) - 2350 sheets - 33.6 Kbps - USB 3.0, USB 2.0 host, USB host, Wi-Fi(n), Gigabit LAN
| Main Specifications | |
|---|---|
| Product Description | Epson WorkForce Enterprise AM-C10000 - multifunction printer - color |
| Device Type | Multifunction printer |
| Fax Type | Super G3 - plain paper |
| Printing Technology | Ink-jet (color) |
| Inkjet Technology | Epson PrecisionCore Heat-Free - 4-ink |
| Monthly Duty Cycle (max) | 960000 pages |
| Recommended Monthly Volume | 25000 - 100000 pages |
| Max Copying Resolution | Up to 600 x 1200 dpi (mono) / up to 600 x 1200 dpi (color) |
| Max Printing Speed | Up to 100 ppm (mono) / up to 100 ppm (color) |
| Max Printing Resolution | Up to 600 x 2400 dpi (mono) / up to 600 x 2400 dpi (color) |
| Max Printing Resolution Class | Up to 600 x 2400 dpi (mono) / up to 600 x 2400 dpi (color) |
| Max Fax Transmission Speed | 33.6 Kbps |
| Scanning | 600 x 600 dpi |
| Original Size | A3 (11.7 in x 16.5 in) (max) |
| Original Type | Sheets |
| Document Feeder Capacity | 150 sheets |
| Media Size | 12.99 in x 47.24 in (max) |
| Media Type | Plain paper, envelopes, colored paper, letterheaded paper, recycled paper |
| Standard Media Capacity | 2350 sheets |
| Max Media Capacity | 5350 sheets |
| Bypass Feeder Capacity | 150 sheets |
| Output Trays Capacity | 550 sheets |
| Automatic Duplexing | Yes (copying) Yes (printing) Yes (scanning) |
| Connection Availability | Yes |
| Interface | USB 3.0, USB 2.0 host, USB host, Wi-Fi(n), Gigabit LAN |
| AirPrint Enabled | Yes |
| Office Machine Features | Scan to e-mail, scan to FTP, scan to USB drive, scan to USB host, fax to folder, fax to e-mail, fax to PC |
| Dimensions (WxDxH) | 26.5 in x 30.1 in x 48.9 in |
| Weight | 399.03 lbs |
| General | |
| Device Type | Multifunction printer |
| Fax Type | Plain paper |
| Printing Technology | Ink-jet - color |
| Monthly Duty Cycle (max) | 960000 pages |
| Recommended Monthly Volume | 25000 - 100000 pages |
| Display Color Support | Color |
| Display Features | Touch screen |
| Connection Availability | Yes |
| Interface | USB 3.0, USB 2.0 host, USB host, Wi-Fi(n), Gigabit LAN |
| AirPrint Enabled | Yes |
| Office Machine Features | Scan to e-mail, scan to FTP, scan to USB drive, scan to USB host, fax to folder, fax to e-mail, fax to PC |
| Memory | |
| Hard Disk Drive | 480 GB |
| Power | |
| Power Consumption Operational | 140 watt |
| Power Consumption Standby | 63 watt |
| Power Consumption Sleep | 0.5 watt |
| Environmental Parameters | |
| Sound Emission | 63 dBA (operating) |
| Connections | |
| Interfaces | 1 x USB 3.0 ¦ 1 x Gigabit LAN ¦ 1 x USB 2.0 host ¦ 1 x USB host |
| Security Protocols & Features | SMB v3, AES, HTTPS, IPsec, IPv4 support, IPv6 support, SNMP 1, SNMP 2c, SNMP 3, TKIP, WEP, WPA3-SAE, WPA-PSK, TLS, Wi-Fi Direct |
| Operating System Support | Apple Mac OS X 10.10.x, Apple Mac OS X 10.11.x, Apple Mac OS X 10.12.x, Apple Mac OS X 10.13.x, Apple Mac OS X 10.6.8, Apple Mac OS X 10.7.x, Apple Mac OS X 10.8.x, Apple Mac OS X 10.9.x, MS Windows 7 (32/64 bits), MS Windows Server 2003 R2, MS Windows Server 2003 SP2, MS Windows Server 2003 SP2 or later, MS Windows Server 2008 R2, MS Windows Server 2016, MS Windows Vista (32/64 bits), MS Windows XP Professional x64 Edition SP2, MS Windows XP SP3, MS Windows XP SP3 or later, Windows 10 (32/64-bits), Windows 11, Windows 8 (32/64-bits), Windows 8.1 (32/64-bits) |
| Software Included | Epson Document Capture Pro, EPSON Scan 2 |
| Copying | |
| Max Copying Resolution | Up to 600 x 1200 dpi (mono) / up to 600 x 1200 dpi (color) |
| Max Document Enlargement | 400% |
| Max Document Reduction | 25% |
| Maximum Copies | 9999 |
| Automatic Duplexing | Yes |
| Printing | |
| Inkjet Technology | Epson PrecisionCore Heat-Free |
| Nozzle Configuration | 8676 nozzles (black), 3 x 8676 nozzles (cyan, magenta, yellow) |
| Max Printing Resolution | Up to 600 x 2400 dpi (mono) / up to 600 x 2400 dpi (color) |
| Max Printing Resolution Class | Up to 600 x 2400 dpi (mono) / up to 600 x 2400 dpi (color) |
| Max Printing Speed | Up to 100 ppm (mono) / up to 100 ppm (color) |
| Ink Cartridge Configuration | 4 cartridges (1 each: cyan, magenta, yellow, black) |
| Ink Palette Supported (Colors) | Pigment cyan, pigment magenta, pigment yellow, pigment black |
| Color | 4-ink |
| Minimum Ink Droplet Size | 3.5 pl |
| Printer Drivers / Emulations | PCL 5c, PCL 6, Adode PostScript 3, EPSON ESC/P, EPSON ESC/P Raster, EPSON ESC/Page, EPSON ESC/Page-Color, PCL 5e, PDF 1.7 |
| Ink Type | Epson DURABrite Pro inks |
| Automatic Duplexing | Yes |
| First Print Out Time B/W | 4.7 sec |
| First Print Out Time Color | 4.7 sec |
| Scanning | |
| Scan Element | CIS |
| Automatic Duplexing | Yes |
| Optical Resolution | 600 x 600 dpi |
| Fax Machine | |
| Compatibility | Super G3 |
| Max Transmission Speed | 33.6 Kbps |
| Total Memory Capacity | Up to 550 pages |
| Fax Machine Features | |
| Error Correction Mode (ECM) | Yes |
| Speed Dialing | 2000 station(s) |
| Features | Color faxing |
| Document & Media Handling | |
| Max Original Size | A3 (11.7 in x 16.5 in) |
| Original Type | Sheets |
| Document Feeder Capacity | 150 sheets |
| Max Media Size | A3/Ledger |
| Min Media Weight | 52 g/m² |
| Max Media Weight | 350 g/m² |
| Supported Media Type | Plain paper, envelopes, colored paper, letterheaded paper, recycled paper |
| Supported Media Sizes | A4 (8.25 in x 11.7 in), A3 (11.7 in x 16.5 in), A5 (5.83 in x 8.25 in), A6 (4.13 in x 5.83 in), Letter A Size (8.5 in x 11 in), B4 (9.83 in x 13.9 in), B5 (6.93 in x 9.83 in), B6 (4.92 in x 6.93 in), Executive (7.25 in x 10.5 in), Legal (8.5 in x 14 in), SRA3+ (12.6 in x 18.11 in) |
| Supported Envelope Sizes | US No 10 (4.1 in x 9.5 in), International DL (4.33 in x 8.66 in), International C6 (4.5 in x 6.38 in), International C4 (9 in x 12.75 in), International C5 (6.38 in x 9 in) |
| Standard Media Capacity | 2350 sheets |
| Max Media Capacity | 5350 sheets |
| Bypass Feeder Capacity | 150 sheets |
| Output Trays Capacity | 550 sheets |
| Document & Media Handling Details | Multi-purpose tray - 150 sheets size: 2.17 in x 5 in - 12.99 in x 47.24 in weight: 52 g/m² - 350 g/m² ¦ Input tray - 550 sheets size: 5.5 in x 7.2 in - Ledger/A3 (11.7 in x 17 in) weight: 52 g/m² - 300 g/m² ¦ 3 x input tray - 550 sheets - SRA3 (12.6 in x 17.7 in) weight: 52 g/m² - 300 g/m² ¦ ADF - 150 sheets |
| Speed Details | Printing: up to 100 ppm - B/W (ISO/IEC 24734) ¦ Printing: up to 100 ppm - color (ISO/IEC 24734) ¦ Printing: up to 100 ppm (A4) - B/W duplex (ISO/IEC 24734) ¦ Printing: up to 100 ppm (A4) - color duplex (ISO/IEC 24734) ¦ Printing: up to 57 ppm (A3) - B/W (ISO/IEC 24734) ¦ Printing: up to 57 ppm (A3) - color (ISO/IEC 24734) ¦ Printing: up to 36.6 ppm (A3) - B/W duplex (ISO/IEC 24734) ¦ Printing: up to 36.6 ppm (A3) - color duplex (ISO/IEC 24734) ¦ Scanning: up to 60 ipm - B/W (200 dpi) ¦ Scanning: up to 60 ipm - color (200 dpi) ¦ Scanning: up to 120 ipm - B/W duplex (200 dpi) ¦ Scanning: up to 120 ipm - color duplex (200 dpi) ¦ Copying: up to 100 ipm - B/W (ISO/IEC 24735) ¦ Copying: up to 100 ipm - color (ISO/IEC 24735) |
| Dimensions & Weight | |
| Width | 26.5 in |
| Depth | 30.1 in |
| Height | 48.9 in |
| Weight | 399.03 lbs |
