Router 1GbE, 2.5GbE - WAN ports: 2 - Wi-Fi 6 - Dual Band - wall-mountable
| Main Specifications | |
|---|---|
| Product Description | Cisco Meraki C8121-W-G2 - router - Wi-Fi 6 - desktop, wall-mountable |
| Device Type | Router |
| Enclosure Type | Desktop, wall-mountable |
| WAN Ports Qty | 2 |
| Data Link Protocol | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Frequency Band | 2.4 GHz / 5 GHz |
| Data Transfer Rate | 1.5 Gbps |
| Performance | NAT/firewall throughput: 2 Gbps ¦ VPN throughput: 1200 Mbps ¦ Advanced security throughput: 1 Gbps |
| Capacity | Recommended number of devices: up to 200 ¦ Spatial streams: 2 |
| Network / Transport Protocol | DHCP |
| Routing Protocol | Static IP routing |
| Features | Cloud managed, auto firmware update, NetFlow, Syslog support, 802.1x authentication, IPSec VPN client, One-to-Many, One-to-One, IDS/IPS support, content filtering, SPIF, IPv6 support, WAN failover, 2x2 MIMO technology, reset button, 45W PoE power budget, PPPoE support, SD-WAN support, VPN client, traffic shaping, VLAN support, WAN load balancing, usage statistics, Advanced Malware Protection |
| Compliant Standards | IEEE 802.3at, IEEE 802.3bt, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Dimensions (WxDxH) | 13.7 in x 8 in x 1.3 in |
| Weight | 3.74 lbs |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | Router |
| Enclosure Type | Desktop, wall-mountable |
| Connectivity Technology | Wired, wireless |
| Data Link Protocol | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Frequency Band | 2.4 GHz / 5 GHz |
| Data Transfer Rate | 1.5 Gbps |
| Performance | NAT/firewall throughput: 2 Gbps ¦ VPN throughput: 1200 Mbps ¦ Advanced security throughput: 1 Gbps |
| Capacity | Recommended number of devices: up to 200 ¦ Spatial streams: 2 |
| Network / Transport Protocol | DHCP |
| Routing Protocol | Static IP routing |
| Features | Cloud managed, auto firmware update, NetFlow, Syslog support, 802.1x authentication, IPSec VPN client, One-to-Many, One-to-One, IDS/IPS support, content filtering, SPIF, IPv6 support, WAN failover, 2x2 MIMO technology, reset button, 45W PoE power budget, PPPoE support, SD-WAN support, VPN client, traffic shaping, VLAN support, WAN load balancing, usage statistics, Advanced Malware Protection |
| Compliant Standards | IEEE 802.3at, IEEE 802.3bt, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Status Indicators | Power, firmware, uplink |
| Expansion / Connectivity | |
| Interfaces | WAN: 1 x 2.5G Gigabit Ethernet - RJ-45 ¦ WAN: 1 x 2.5G Multi-Gigabit Ethernet (PoE+) - RJ-45 ¦ LAN: 3 x 1000Base-T (UPOE) - RJ-45 ¦ LAN: 7 x 1000Base-T |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Power | |
| Power Device | External power adapter - 250 watt |
| Power Consumption Operational | 56 watt |
| Software / System Requirements | |
| Software Included | Meraki Dashboard |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 5 - 95% |
| Dimensions & Weight | |
| Width | 13.7 in |
| Depth | 8 in |
| Height | 1.3 in |
| Weight | 3.74 lbs |
| Antenna | |
| Antenna | Internal |
