Docking station - Thunderbolt 5 - HDMI, Thunderbolt - 2.5GbE - 180 watt
| Main Specifications | |
|---|---|
| Product Description | Belkin CONNECT - docking station - Thunderbolt 5 - HDMI, Thunderbolt - 2.5GbE |
| Product Type | Docking station |
| Docking Interface | Thunderbolt 5 |
| Video Interfaces | HDMI, Thunderbolt |
| Dimensions (WxDxH) | 8.9 in x 3.4 in x 1.1 in |
| Networking | 2.5 Gigabit Ethernet |
| Power | Power adapter 180 watt Power Provided |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | Docking station |
| Width | 8.9 in |
| Depth | 3.4 in |
| Height | 1.1 in |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) x SD Memory Card ¦ 1 (total) / 1 (free) x microSD |
| Interfaces | 1 x Thunderbolt 5 with Power Delivery (140W) - 24 pin USB-C ¦ 2 x USB-C / Thunderbolt 5 with Power Delivery (15 W) - 24 pin USB-C ¦ 1 x USB-A 3.2 (4.5 W) - 9 pin USB Type A ¦ 1 x USB-C 3.2 - 24 pin USB-C ¦ 2 x SuperSpeed USB 3.0 - 9 pin USB Type A ¦ 1 x USB-C 3.2 Gen 2 (30 W) - 24 pin USB-C ¦ 1 x audio / video - DisplayPort - 20 pin DisplayPort (2.1) ¦ 1 x audio / video - HDMI - 19 pin HDMI Type A ¦ 1 x network - 2.5G Gigabit Ethernet - RJ-45 ¦ 1 x headphone/microphone combo jack - headphones/microphone - mini-phone 3.5 mm |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 30 day money back guarantee - 3 years |
| Miscellaneous | |
| Input Device | SD card reader, microSD card reader |
| Cables Included | 1 x Thunderbolt 5 cable - 3.3 ft |
| Features | Up to 140W power delivery, up to 120 Gbps Thunderbolt bandwidth (boost mode), 80 Gbps Thunderbolt bandwidth |
| Compliant Standards | Thunderbolt 5, USB Power Delivery 3.0 |
| Networking | |
| Data Link Protocol | 2.5 Gigabit Ethernet |
| Compliant Standards | USB 3.2, USB 3.0 |
| Power | |
| Power Device | Power adapter |
| Power Provided | 180 watt |
| Video | |
| Max Resolution Details | 4K - 144 Hz (Triple Display) ¦ 8K - 60 Hz |
