Video/audio/infrared/serial extender - transmitter - HDMI, HDBaseT - up to 230 ft
| Main Specifications | |
|---|---|
| Product Description | Kramer TP-583T - video/audio/infrared/serial extender - HDMI, HDBaseT |
| Device Type | Video/audio/infrared/serial extender (transmitter) |
| Form Factor | External |
| Data Link Protocol | HDMI, HDBaseT |
| Max Transfer Distance | 230 ft |
| Dimensions (WxDxH) | 4.7 in x 2.8 in x 1 in |
| Weight | 10.58 oz |
| General | |
| Device Type | Video/audio/infrared/serial extender (transmitter) |
| Form Factor | External |
| Expansion / Connectivity | |
| Interfaces | 1 x HDMI (input) - 19 pin HDMI Type A female ¦ 1 x HDBaseT (output) - RJ-45 female ¦ 1 x RS-232 - 3 pin terminal block ¦ 1 x remote control - mini jack female |
| Miscellaneous | |
| Compliant Standards | UL, RoHS, WEEE |
| Networking | |
| Connectivity Technology | Wired |
| Data Link Protocol | HDMI, HDBaseT |
| Max Resolution | 4096 x 2160 @ 60 Hz |
| Max Transfer Distance | 230 ft |
| Status Indicators | Power, link/activity, input, output |
| Features | 3D support, HDBaseT technology, I-EDIDPro Kramer Intelligent EDID Processing, Dolby TrueHD support, DTS-HD support, HDR10 support, 4:4:4 chroma subsampling support, Deep Color support |
| Compliant Standards | HDCP 2.2 |
| Power | |
| Power Device | External power adapter |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 4.7 in |
| Depth | 2.8 in |
| Height | 1 in |
| Weight | 10.58 oz |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 6.2 in |
| Shipping Depth | 4.7 in |
| Shipping Height | 3.4 in |
| Shipping Weight | 24.69 oz |
