AI Workstation, Copilot+ PC - Intel Core Ultra 7 - 368H / up to 5 GHz - vPro Enterprise - Win 11 Pro - Arc B390 - 32 GB RAM - 1 TB SSD TCG Opal Encryption 2, NVMe, Performance - 16" IPS 3840 x 2400 (WQUXGA) - Wi-Fi 7, Bluetooth - 5G upgradable - black - kbd: US - with 1 Year Lenovo Premier Support
| Main Specifications | |
|---|---|
| Product Description | Lenovo ThinkPad P1 Gen 9 - AI Workstation, Copilot+ PC - 16" - Intel Core Ultra 7 - 368H - vPro Enterprise - 32 GB RAM - 1 TB SSD - 5G upgradable - US |
| Product Type | Mobile workstation - AI Workstation, Copilot+ PC |
| EU Data Act | Https://www.lenovo.com/us/en/compliance/eu-data-act-transparency-declaration/ |
| Operating System | Win 11 Pro - English |
| Platform Technology | Intel vPro Enterprise |
| Processor | Intel Core Ultra 7 (Series 3) - 368H / 2 GHz, up to 5 GHz / 18 MB Cache |
| Neural Processor Unit (NPU) | - up to 50 TOPS |
| Memory | 32 GB LPDDR5X SDRAM (1 x 32 GB) |
| Storage | 1 TB SSD - TCG Opal Encryption 2, NVMe, Performance |
| Display | 16" 3840 x 2400 / WQUXGA @ 60 Hz |
| Graphics | Intel Arc B390 - up to 122 TOPS |
| Input Device | Keyboard, TrackPoint, UltraNav |
| Keyboard | US |
| Keyboard Backlight | Yes |
| Integrated Webcam | Yes |
| Networking | 802.11a/b/g/n/ac/ax/be, Bluetooth 5.4 |
| Wireless Broadband (WWAN) | 5G upgradable |
| Security | Discrete Trusted Platform Module (TPM 2.0) Security Chip, fingerprint reader |
| Color | Black |
| Dimensions (WxDxH) | 14 in x 9.5 in x 0.8 in |
| Weight | 3.97 lbs |
| Localization | Language: English / region: United States |
| Manufacturer Selling Program | Lenovo TopSeller |
| Environmental Standards | ENERGY STAR Qualified EPEAT Gold |
| Specific Absorption Rate (SAR) | 1.266 W/kg (body) ¦ 3.164 W/kg (limb) |
| Manufacturer Warranty | Base warranty - 1 year - pick-up and return ¦ Extended warranty - 1 year - on-site - response time: next business day |
| Bundled Services | 1 Year Lenovo Premier Support |
| General | |
| Product Type | Mobile workstation |
| AI Level | AI Workstation, Copilot+ PC |
| Operating System | Windows 11 Pro - English |
| EU Data Act | Https://www.lenovo.com/us/en/compliance/eu-data-act-transparency-declaration/ |
| Memory | |
| RAM | 32 GB (1 x 32 GB) |
| Max RAM Supported | 96 GB |
| Technology | LPDDR5X SDRAM |
| Speed | 8533 MT/s |
| Rated Speed | 8533 MT/s |
| Form Factor | LPCAMM2 |
| Slots Qty | 1 |
| Empty Slots | 0 |
| Manufacturer Warranty | |
| Service & Support | Base warranty - 1 year - pick-up and return ¦ Extended warranty - 1 year - on-site - response time: next business day |
| Bundled Services | 1 Year Lenovo Premier Support |
| Miscellaneous | |
| Color | Black |
| Case Material | Aluminum (top), aluminum (bottom) |
| Security | Discrete Trusted Platform Module (TPM 2.0) Security Chip, fingerprint reader |
| Features | NVMe password, power-on password, administrator password, self-healing BIOS, bottom cover tamper detection, MIL-STD-810H tested, RapidCharge |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington nano security slot |
| Included Accessories | USB-C GaN power adapter |
| Compliant Standards | RoHS, TCG Certified, TÜV Rheinland Low Blue Light, Eyesafe Certified 2.0 |
| Specific Absorption Rate (SAR) | 1.266 W/kg (body) ¦ 3.164 W/kg (limb) |
| Localization | Language: English / region: United States |
| Manufacturer Selling Program | Lenovo TopSeller |
| Storage | |
| Main Storage | 1 TB SSD M.2 2280 PCIe 5.0 x4 - TCG Opal Encryption 2, NVM Express (NVMe), Performance |
| RAID Level | RAID 0, RAID 1 |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 8 - 95% |
| Software | |
| Software Included | Lenovo AI Now, Intel Connectivity Performance Suite, ThinkShield Pro (1 year) |
| Battery | |
| Technology | Lithium ion |
| Capacity | 90 Wh |
| Display | |
| Type | 16" - IPS |
| Resolution | 3840 x 2400 (WQUXGA) |
| V-Sync Rate at Max Res. | 60 Hz |
| Widescreen | Yes |
| Image Aspect Ratio | 16:10 |
| Image Brightness | 800 cd/m² |
| Horizontal Viewing Angle | +85 / -85 |
| Vertical Viewing Angle | +85 / -85 |
| Color Gamut | 100% DCI-P3 |
| Features | Anti-glare, 91.7% screen-to-body ratio, HDR400, Dolby Vision, Eyesafe technology, Low Blue Light technology, X-Rite factory color calibration, DC dimming |
| Communications | |
| Wireless | 802.11a/b/g/n/ac/ax/be, Bluetooth 5.4 |
| Wireless Controller | Intel WI-FI 7 BE211 |
| Features | Dual stream (2x2) |
| Dimensions & Weight | |
| Dimensions (WxDxH) | 14 in x 9.5 in x 0.8 in |
| Weight | 3.97 lbs |
| Processor / Chipset | |
| CPU | Intel Core Ultra 7 (Series 3) 368H / 2 GHz |
| Max Turbo Speed | 5 GHz |
| Number of Cores | 16-core |
| Performance Cores | 4 |
| Efficient Cores | 12 |
| Cache | L3 - 18 MB |
| Platform Technology | Intel vPro Enterprise |
| Features | Integrated memory controller, Intel Smart Cache |
| Audio & Video | |
| Graphics Processor | Intel Arc B390 - up to 122 TOPS |
| Max Monitors Supported | 3 external monitor(s) |
| Camera | Yes |
| Resolution | 5 Megapixel |
| Camera Features | Privacy shutter, IR camera, Windows Hello, fixed focus, Temporal Noise Reduction, Computer Vision Human Presence Detection on ISP |
| Sound | Quad speakers, dual array microphone |
| Codec | CS42L43 |
| Compliant Standards | Dolby Atmos, SoundWire |
| Audio Features | Input: Dolby Voice, far-field |
| Input | |
| Type | Keyboard, TrackPoint, UltraNav |
| Keyboard Backlight | Yes |
| Keyboard Layout | US |
| Features | Multimedia control, spill-resistant, Copilot key, glass touchpad, haptic touchpad, multi-touch touchpad |
| AC Adapter | |
| Input | AC 100-240 V (50/60 Hz) |
| Output | 140 watt |
| Connections & Expansion | |
| Slots | 1 x M.2 (PCI Express 4.0 x4) (1 available) ¦ 1 x Nano-SIM card (1 available) |
| Interfaces Details | USB 3.2 Gen 2 (Always On) ¦ 2 x Thunderbolt 5/DisplayPort 2.1 (Power Delivery 3.1, 140 W input / 15 W output) ¦ Thunderbolt 4/DisplayPort 2.1 (Power Delivery 3.1, 140 W input / 15 W output) ¦ HDMI (8K support) ¦ Headphone/microphone combo jack (mini-phone 3.5 mm) |
| Memory Card Reader | Yes (SD Express Card) |
| Wireless Broadband (WWAN) | |
| Generation | 5G upgradable |
| Sustainability Information | |
| EPEAT Compliant | EPEAT Gold |
| ENERGY STAR Certified | Yes |
| Packaging Recycled Content | 90 % - plastic-free, recycled and/or FSC certified |
| Neural Processor Unit (NPU) | |
| NPU Performance Up To (TOPS) | 50 TOPS |
| AI Datatype Support on NPU | INT8 |
| Sparsity Support | Yes |
| AI Software Frameworks Supported by NPU | OpenVINO, WebNN, WindowsML, ONNX RT |
| Windows Studio Effects Support | Yes |
