Router 8-port switch - 2.5GbE, 5GbE, 10GbE, 25GbE - WAN ports: 2 - rack-mountable - for P/N: UACC-CABLE-PATCH-EL-C6A-0.15M-W, UACC-CM-RJ45-MG, UACC-OM-SFP28-LR
| Main Specifications | |
|---|---|
| Product Description | Ubiquiti UniFi Dream Machine Beast - router - rack-mountable |
| Device Type | Router - 8-port switch (integrated) |
| Enclosure Type | Rack-mountable - 1U |
| WAN Ports Qty | 2 |
| Data Link Protocol | Fast Ethernet, Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, 25 Gigabit Ethernet |
| Performance | IDS/IPS throughput: 25 Gbps |
| Capacity | Number of UniFi supported devices: 750 ¦ Maximum cameras: 100 ¦ Managed hubs: 200 ¦ Simultaneous users: 7500 |
| Network / Transport Protocol | IPSec, OpenVPN, L2TP, IPv6 |
| Routing Protocol | OSPF, BGP, IGMP |
| Remote Management Protocol | DHCP |
| Features | Reset button, VRRP support, application-aware layer 7 firewall, DPI & traffic identification, zone-based firewall advanced filtering, content filtering, IPS, IDP, ad blocking, OpenVPN server, WireGuard, OpenVPN client, multi-WAN load balancing, LACP port aggregation, Advanced QoS, mDNS, DNAT support, SNAT support, Internet quality, outage reporting, policy-based WAN, VPN routing, DHCP server, IGMP proxy, aluminum/steel housing, Bluetooth management, 4KV ESD Protector (contact discharge), 8KV ESD Protector (air-gap discharge), safety latch |
| Power | AC 100-240 V (50/60 Hz) |
| Dimensions (WxDxH) | 17.4 in x 12.8 in x 1.7 in |
| Weight | 12.13 lbs |
| Designed For | P/N: UACC-CABLE-PATCH-EL-C6A-0.15M-W, UACC-CM-RJ45-MG, UACC-DAC-SFP10-0.5M, UACC-DAC-SFP28-0.5M, UACC-OM-SFP28-LR |
| General | |
| Device Type | Router - 8-port switch (integrated) |
| Enclosure Type | Rack-mountable - 1U |
| Connectivity Technology | Wired |
| Data Link Protocol | Fast Ethernet, Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, 25 Gigabit Ethernet |
| Performance | IDS/IPS throughput: 25 Gbps |
| Capacity | Number of UniFi supported devices: 750 ¦ Maximum cameras: 100 ¦ Managed hubs: 200 ¦ Simultaneous users: 7500 |
| MAC Address Table Size | 32000 entries |
| Network / Transport Protocol | IPSec, OpenVPN, L2TP, IPv6 |
| Routing Protocol | OSPF, BGP, IGMP |
| Remote Management Protocol | DHCP |
| Encryption Algorithm | TLS |
| Authentication Method | RADIUS, RADSEC |
| Features | Reset button, VRRP support, application-aware layer 7 firewall, DPI & traffic identification, zone-based firewall advanced filtering, content filtering, IPS, IDP, ad blocking, OpenVPN server, WireGuard, OpenVPN client, multi-WAN load balancing, LACP port aggregation, Advanced QoS, mDNS, DNAT support, SNAT support, Internet quality, outage reporting, policy-based WAN, VPN routing, DHCP server, IGMP proxy, aluminum/steel housing, Bluetooth management, 4KV ESD Protector (contact discharge), 8KV ESD Protector (air-gap discharge), safety latch |
| Compliant Standards | NDAA, IC, FCC |
| Processor | 1 x ARM 2.1 GHz |
| RAM | 16 GB |
| Built-in Devices | 1.3" touch screen display, 128 GB SSD |
| Status Indicators | Link/activity, disk, RPS (Redundant Power Supply), SFP+ |
| Expansion / Connectivity | |
| Interfaces | LAN: 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ LAN: 7 x 10Gb Ethernet - RJ-45 ¦ WAN: 1 x 10Gb Ethernet - RJ-45 ¦ WAN: 1 x 25Gb Ethernet - SFP28 ¦ LAN: 1 x 25Gb Ethernet - SFP28 ¦ LAN: 2 x 10Gb Ethernet - SFP+ ¦ Console: 1 x |
| Expansion Slots | 2 (total) / 2 (free) x 3.5" HDD bay |
| Miscellaneous | |
| Included Accessories | Power cable |
| Rack Mounting Kit | Included |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Dimensions & Weight | |
| Width | 17.4 in |
| Depth | 12.8 in |
| Height | 1.7 in |
| Weight | 12.13 lbs |
| Compatibility Information | |
| Designed For | P/N: UACC-CABLE-PATCH-EL-C6A-0.15M-W, UACC-CM-RJ45-MG, UACC-DAC-SFP10-0.5M, UACC-DAC-SFP28-0.5M, UACC-OM-SFP28-LR |
