LED monitor - 2MP - color - 21" (21.3" viewable) - 1600 x 1200 - IPS-SFT - 1000 cd/m² - 2000:1 - 12 ms - 2xDisplayPort - black, RAL 9004, white, RAL 9003
| Main Specifications | |
|---|---|
| Product Description | Barco Nio Color 2MP - LED monitor - 2MP - color - 21" |
| Device Type | LED-backlit LCD monitor - 2MP - color - 21" |
| Features | KVM switch, USB 2.0 hub, presence sensor, ambient light sensor |
| Panel Type | IPS-SFT |
| Aspect Ratio | 4:3 |
| Native Resolution | 1600 x 1200 |
| Pixel Pitch | 0.27 mm |
| Brightness | 1000 cd/m² |
| Contrast Ratio | 2000:1 |
| Response Time | 12 ms (gray-to-gray) |
| Color Support | 1.07 billion colors (30-bit) |
| Input Connectors | 2xDisplayPort |
| Display Position Adjustments | Height, pivot (rotation) |
| Screen Coating | Anti-reflective |
| Color | Black, RAL 9004, white, RAL 9003 |
| Dimensions (WxDxH) - with stand | 19.3 in x 8.9 in x 22.1 in |
| Compliant Standards | VCCI, DEMKO, FCC Part 15 B, CCC, RoHS, ICES Class B, KCC, FDA 510k, CAN/CSA C22.2 No. 60601-1, ANSI/AAMI ES60601-1:2005, IEC 60601-1:2005 + A1:2012 + A2:2020, IEC 60601-1-2:2014 + A1:2020 (Ed 4.1), IEC 60950-1:2005+A1:2009+A2:2013 (International), CE0123, BSMI, REACH, WEEE, Canada Health, Packaging Directive, ICES-001 level B, EU RoHS, China RoHS |
| Manufacturer Warranty | 5-year warranty |
| General | |
| Display Type | LED-backlit LCD monitor / TFT active matrix - 2MP - color |
| Diagonal Size | 21" |
| Viewable Size | 21.3" |
| Built-in Devices | KVM switch, USB 2.0 hub, presence sensor, ambient light sensor |
| Panel Type | IPS-SFT |
| Aspect Ratio | 4:3 |
| Native Resolution | 1600 x 1200 |
| Pixel Pitch | 0.27 mm |
| Brightness | 1000 cd/m² |
| Contrast Ratio | 2000:1 |
| Color Support | 1.07 billion colors (30-bit) |
| Response Time | 12 ms (gray-to-gray) |
| Horizontal Viewing Angle | 178 |
| Vertical Viewing Angle | 178 |
| Screen Coating | Anti-reflective |
| Backlight Technology | LED backlight |
| Features | Integrated Front Sensor, Uniform Luminance Technology (ULT), 30-bit color depth, RapidFrame |
| Color | Black, RAL 9004, white, RAL 9003 |
| Dimensions (WxDxH) | 19.3 in x 8.9 in x 22.1 in - with stand |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Features | Portrait / landscape mode |
| Included Accessories | Protective cover |
| Backlight Life | 20,000 hours |
| Compliant Standards | VCCI, DEMKO, FCC Part 15 B, CCC, RoHS, ICES Class B, KCC, FDA 510k, CAN/CSA C22.2 No. 60601-1, ANSI/AAMI ES60601-1:2005, IEC 60601-1:2005 + A1:2012 + A2:2020, IEC 60601-1-2:2014 + A1:2020 (Ed 4.1), IEC 60950-1:2005+A1:2009+A2:2013 (International), CE0123, BSMI, REACH, WEEE, Canada Health, Packaging Directive, ICES-001 level B, EU RoHS, China RoHS |
| Software / System Requirements | |
| Included Software | Barco QAWeb Enterprise |
| Connectivity | |
| Interfaces | 2 x DisplayPort 1.4 ¦ 2 x USB 2.0 upstream (Type B) ¦ 5 x USB 2.0 downstream (Type A) |
| Dimensions & Weight | |
| Dimensions & Weight Details | With stand - width: 19.3 in - depth: 8.9 in - height: 22.1 in ¦ Without stand - width: 19.3 in - depth: 2.5 in - height: 13.8 in |
| Mechanical | |
| Display Position Adjustments | Height, pivot (rotation) |
| Height Adjustment | 3.9 in |
| VESA Mounting Interface | 100 x 100 mm |
