Switch - industrial, -40°C to 75°C - unmanaged - 8 x 10/100/1000 (PoE+) + 2 x 1000Base-X SFP (uplink) - DIN rail mountable - PoE+ (240 W) - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite series - switch - industrial, -40°C to 75°C - 8 ports - unmanaged - TAA Compliant |
| Device Type | Switch - 8 ports - unmanaged |
| Subtype | Gigabit Ethernet |
| Ports | 8 x 10/100/1000 (PoE+) + 2 x 1000Base-X SFP (uplink) |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 240 W |
| Performance | Switching capacity: 20 Gbps |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 10000 bytes |
| Features | Auto-negotiation, QoS, metal housing, 8KV ESD Protector (air-gap discharge), 4KV ESD Protector (contact discharge), MAC address auto-learning, Storm Control, auto-uplink (auto MDI/MDI-X), fanless, flow control, rugged |
| Compliant Standards | IEEE 802.3x, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at |
| Power | DC 48 - 57 V |
| Power Redundancy | Yes |
| Dimensions (WxDxH) | 2 in x 4.7 in x 6.3 in |
| Weight | 14.81 oz |
| Color | Black |
| TAA Compliant | Yes |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Switch - 8 ports - unmanaged |
| Enclosure Type | DIN rail mountable |
| Subtype | Gigabit Ethernet |
| Ports | 8 x 10/100/1000 (PoE+) + 2 x 1000Base-X SFP (uplink) |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 240 W |
| Performance | Switching capacity: 20 Gbps |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 10000 bytes |
| Features | Auto-negotiation, QoS, metal housing, 8KV ESD Protector (air-gap discharge), 4KV ESD Protector (contact discharge), MAC address auto-learning, Storm Control, auto-uplink (auto MDI/MDI-X), fanless, flow control, rugged |
| Compliant Standards | IEEE 802.3x, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at |
| Status Indicators | Power, RPS (Redundant Power Supply), alarm, PoE, port transmission speed, link/activity, SFP |
| Expansion / Connectivity | |
| Interfaces | 8 x 10/100/1000 Base-T (PoE) RJ-45 30 W ¦ 2 x 1000Base-X SFP |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Color | Black |
| Included Accessories | Dust cover |
| Compliant Standards | RoHS, IP30, Plug and Play |
| TAA Compliant | Yes |
| Power | |
| Power Redundancy | Yes |
| Voltage Required | DC 48 - 57 V |
| Power Consumption Operational | 13 watt |
| Environmental Parameters | |
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 167 °F |
| Humidity Range Operating | 5 - 95% RH (non-condensing) |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 185 °F |
| Dimensions & Weight | |
| Width | 2 in |
| Depth | 4.7 in |
| Height | 6.3 in |
| Weight | 14.81 oz |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 2.4 in |
| Shipping Depth | 7.2 in |
| Shipping Height | 9.2 in |
| Shipping Weight | 32.45 oz |
