Conference camera - color - 20.3 MP - 1080p, 720p - GbE - USB-C - PoE
| Main Specifications | |
|---|---|
| Product Description | Huddly L1 - conference camera |
| Device Type | Conference camera - fixed |
| Camera Mount Type | Wall mount |
| Dimensions (WxDxH) | 4.8 in x 3.5 in x 2.1 in |
| Weight | 28.22 oz |
| Color | Black |
| Connectivity Technology | Wired |
| Camera | Color |
| Frame Rate (max) | 30 frames per second |
| Video Modes | 1080p, 720p |
| Optical Sensor Type | CMOS - 1" - 20.3 MP |
| Lens Iris | F/2.9 |
| Interfaces | USB-C Ethernet 10Base-T/100Base-TX/1000Base-T |
| Software Certification | Certified for Microsoft Teams |
| Cables Included | 1 - network cable - external - 6.6 ft ¦ 1 - USB-C cable - external - 2 ft |
| Voltage | PoE |
| Features | Group framing, Gallery View, Speaker mode, Collaboration mode, People count, Facebased exposure, 2.4 µm pixel size, 180° image auto-flip, Huddly Director, aluminum housing, portrait lighting, InSights Analytics, USB Video Device Class (UVC) mode |
| Environmental Parameters (operating) | 32 °F - 95 °F; 85% RH relative humidity |
| General | |
| Device Type | Conference camera |
| Camera Mount Type | Wall mount |
| Connectivity Technology | Wired |
| Width | 4.8 in |
| Depth | 3.5 in |
| Height | 2.1 in |
| Weight | 28.22 oz |
| Expansion / Connectivity | |
| Ports | LAN - RJ-45 ¦ USB-C - 24-pin USB-C |
| Miscellaneous | |
| Included Accessories | Wall mount bracket, USB adapter |
| Cables Included | 1 x network cable - external - 6.6 ft ¦ 1 x USB-C cable - external - 2 ft |
| Software Certification | Certified for Microsoft Teams |
| Color | Black |
| Power | |
| Power Requirements | PoE |
| Power Device | Power adapter - external |
| Software / System Requirements | |
| OS Required | Windows 10 or later, Apple MacOS, Google Chrome OS |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 95 °F |
| Relative Humidity (operating) | 85% RH |
| Camera | |
| Type | Color - fixed |
| Video Modes | 1080p, 720p |
| Digital Zoom | 5 |
| Frame Rate (max) | 30 frames per second |
| Features | Group framing, Gallery View, Speaker mode, Collaboration mode, People count, Facebased exposure, 2.4 µm pixel size, 180° image auto-flip, Huddly Director, aluminum housing, portrait lighting, InSights Analytics, USB Video Device Class (UVC) mode |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 7.6 in |
| Shipping Depth | 10.8 in |
| Shipping Height | 3.8 in |
| Shipping Weight | 3.97 lbs |
| Lens Construction | |
| Lens Iris | F/2.9 |
| Horizontal Field of View (degree) | 92 |
| Vertical Field of View (degree) | 65 |
| Diagonal Field of View (degree) | 103 |
| Image Sensor | |
| Type | 20.3 MP CMOS 1" |
| Interfaces | |
| Network Interface | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Computer Interface | USB-C |
