Amplifier - 4 x 160 watt
| Main Specifications | |
|---|---|
| Product Description | LEA Professional Connect Series 164 - amplifier |
| Product Type | Amplifier |
| Audio Specifications | Amplifier - 20 - 20000 Hz - 105 dB 0.1% |
| Display | LCD display |
| Power | AC 100-240 V (50/60 Hz) |
| Dimensions (WxDxH) | 19 in x 14.3 in x 1.7 in |
| Weight | 12.1 lbs |
| Manufacturer Warranty | 5-year warranty |
| General | |
| Product Type | Amplifier |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 6 years |
| Power | |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Display | |
| Display Type | LCD display |
| Connections | |
| Connectors | LAN (RJ-45) ¦ Analog input (3 pin amphenol anytek) ¦ Analog output (2 pin amphenol anytek) ¦ External IO (3 pin amphenol anytek) |
| Dimensions & Weight | |
| Width | 19 in |
| Depth | 14.3 in |
| Height | 1.7 in |
| Weight | 12.1 lbs |
| Audio System | |
| Functions | Amplifier |
| Amplifier Class | D |
| Digital Sound Processor (DSP) | Yes |
| Audio Specifications | Amplifier - Response Bandwidth - 20 - 20000 Hz - SNR - 105 dB - THD - 0.1% |
| Output Channel Qty | 4 channels |
| Output Power (per channel) | 160 watt |
| Amplifier Output Details | 60 watt - 2 ohm |
| Features | 25V/70V/100V or 2/4/8 Ohm operation, Wi-Fi compatible |
| Dimensions & Weight (Shipping) | |
| Weight (Shipping) | 16.4 lbs |
