Docking station - USB4 - HDMI, USB-C - North America
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series - docking station - USB4 - HDMI, USB-C |
| Product Type | Docking station |
| Docking Interface | USB4 |
| Video Interfaces | HDMI, USB-C |
| Dimensions (WxDxH) | 2 in x 5.7 in x 0.6 in |
| Weight | 5.29 oz |
| Color | Black, gray |
| Localization | North America |
| Power | USB |
| Manufacturer Warranty | 1-year limited warranty |
| General | |
| Product Type | Docking station |
| Width | 2 in |
| Depth | 5.7 in |
| Height | 0.6 in |
| Weight | 5.29 oz |
| Enclosure Color | Black, gray |
| Localization | North America |
| Expansion / Connectivity | |
| Interfaces | 2 x video - HDMI - 19 pin HDMI Type A ¦ 1 x USB 3.2 Gen 2 - 9 pin USB Type A ¦ 1 x USB-C 3.2 Gen 2 - 24 pin USB-C ¦ 1 x USB-C 3.2 Gen 2 with Power Delivery - 24 pin USB-C (100 Watt passthrough) ¦ 1 x USB 2.0 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Cables Included | 1 x USB4 cable - integrated - 7.9 in |
| Features | 100W power delivery, 4K144Hz support, up to 10Gbps data transfer, HDR support, DisplayPort Alt Mode, Display Stream Compression (DSC), 4:4:4 chroma subsampling, 4:2:0 chroma subsampling, 4:2:2 profile support, 36-bit True Color, box package, Mirror Mode, EDID PassThru, overcurrent protection, overvoltage protection, MST (multi-stream transport) |
| Compliant Standards | FCC Part 15 Class B (USA), REACH, RoHS3, UKCA, WEEE, ICES (Canada), Mexico NOM, EN 55032, Plug and Play |
| Networking | |
| Compliant Standards | USB 2.0, USB 3.0, USB 3.2 Gen 1, USB 3.2 Gen 2, HDCP 2.3, HDCP 1.4 |
| Power | |
| Power Device | USB |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Video | |
| Max Resolution Details | 8K - 30 Hz |
