Docking station - USB4 - DP, USB-C - 1GbE, 2.5GbE - North America
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series - docking station - USB4 - DP, USB-C - 1GbE, 2.5GbE |
| Product Type | Docking station |
| Docking Interface | USB4 |
| Video Interfaces | DP, USB-C |
| Dimensions (WxDxH) | 0.9 in x 7.5 in x 3.1 in |
| Weight | 11.64 oz |
| Color | Silver |
| Localization | North America |
| Networking | Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Power | Power supply (50/60 Hz) (AC 100-240 V) |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | Docking station |
| Width | 0.9 in |
| Depth | 7.5 in |
| Height | 3.1 in |
| Weight | 11.64 oz |
| Enclosure Color | Silver |
| Localization | North America |
| Expansion / Connectivity | |
| Interfaces | 3 x USB 3.2 Gen 2 - 24 pin USB-C ¦ 2 x USB 3.2 Gen 2 - 9 pin USB Type A ¦ 1 x network - 1000Base-T - RJ-45 ¦ 2 x audio / video - DisplayPort - 20 pin DisplayPort (1.4) ¦ 1 x USB 2.0 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Cables Included | 1 x USB4 cable - external - 3.3 ft |
| Features | Dual display support, 96W power delivery, 4K144Hz support, PC/ABS housing, 4:4:4 chroma subsampling, 4:2:0 chroma subsampling, 4:2:2 profile support, EDID PassThru, Mirror Mode, 3D video support, DisplayPort Alt Mode, Display Stream Compression (DSC), up to 10Gbps data transfer |
| Compliant Standards | FCC Part 15 Class B (USA), ICES-003 issue 7, UL 62368-1, ICES (Canada), CAN/CSA-C22.2 No. 62368-1 |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Compliant Standards | USB 2.0, USB 3.0, USB 3.2 Gen 1, USB 3.2 Gen 2, HDCP 2.3 |
| Power | |
| Power Device | Power supply |
| Voltage Required | (50/60 Hz) |
| Voltage Provided | AC 100-240 V |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Video | |
| Max Resolution Details | 8K - 30 Hz |
