Backpack PC 1 x N-series N355 / up to 3.9 GHz - RAM 16 GB - SSD 256 GB - NVMe - Intel Graphics - Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.3 - no OS - monitor: none - black
| Main Specifications | |
|---|---|
| Product Description | Elo Backpack - backpack PC N-series N355 - 16 GB - SSD 256 GB |
| Type | Point of sale terminal - backpack PC |
| Processor | 1 x Intel N-series N355 (up to 3.9 GHz, (8-core) |
| Processor Main Features | 8 Threads, Intel Smart Cache, Intel Turbo Boost Technology 3 |
| Cache Memory | 6 MB |
| Cache Per Processor | 6 MB |
| RAM | 16 GB (installed) / 16 GB (max) - DDR5 SDRAM |
| Hard Drive | SSD 256 GB - PCI Express - M.2 - NVM Express (NVMe) |
| Optical Storage | No optical drive |
| Graphics Controller | Intel Graphics |
| Networking | 1GbE, 802.11a, Wi-Fi 5, Wi-Fi 6, 802.11b/g/n, Bluetooth 5.3 |
| Power | (50/60 Hz) |
| OS Provided | No operating system |
| Color | Black |
| Dimensions (WxDxH) | 5.5 in x 4.5 in x 1.7 in |
| Weight | 34.21 oz |
| Manufacturer Warranty | Limited warranty - 3 years |
| General | |
| Type | Point of sale terminal |
| Product Form Factor | Backpack PC |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Color | Black |
| Expansion / Connectivity | |
| Interfaces | HDMI ¦ DisplayPort ¦ 2 x USB 3.2 Gen 2 ¦ USB 3.2 Gen 1 ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 ¦ USB 2.0 ¦ 2 x DisplayPort/USB-C ¦ Headphones/microphone |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | Power adapter, 2 x antennas, 4 x screws M4 x 40 mm, 4 x screws M4 x 5 mm, 2 mounting brackets |
| Cables Included | USB-C cable |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington nano security slot |
| VESA Mounting Interface | VESA, 100 mm |
| Compliant Standards | UL, cUL, FCC, TUV, RCM, UKCA, CB, VCCI, MIC, CCC, SRRC, Mexico NOM, RoHS |
| RAM | |
| Installed Size | 16 GB (installed) / 16 GB (max) |
| Technology | DDR5 SDRAM |
| Effective Memory Speed | 4800 MHz |
| Rated Memory Speed | 4800 MHz |
| Form Factor | SO-DIMM 262-pin |
| Networking | |
| Wireless LAN Supported | Yes |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Bluetooth 5.3 |
| Power | |
| Device Type | Power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 25.5 Watt |
| Power Consumption Sleep | 2 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% |
| Cache Memory | |
| Installed Size | 6 MB |
| Cache Per Processor | 6 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel Graphics |
| Video Interfaces | HDMI, DisplayPort |
| Operating System / Software | |
| OS Provided | No operating system |
| Hard Drive | |
| Type | SSD - M.2 |
| Capacity | 1 x 256 GB |
| Interface Type | PCI Express |
| Features | NVM Express (NVMe) 160 TBW |
| Input Device | |
| Type | No keyboard, no mouse |
| Dimensions & Weight | |
| Width | 5.5 in |
| Depth | 4.5 in |
| Height | 1.7 in |
| Weight | 34.21 oz |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 14.9 in |
| Shipping Depth | 8.1 in |
| Shipping Height | 3.2 in |
| Shipping Weight | 5 lbs |
| Processor / Chipset | |
| CPU | Intel N-series N355 |
| Max Turbo Speed | 3.9 GHz |
| Number of Cores | 8-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Processor Main Features | 8 Threads, Intel Smart Cache, Intel Turbo Boost Technology 3 |
