Label printer - direct thermal / thermal transfer - Roll (149.6 cm) - 203 dpi - up to 720.5 inch/min - USB 2.0, USB host, Gigabit LAN
| Main Specifications | |
|---|---|
| Product Description | Toshiba BX620T - label printer - direct thermal / thermal transfer |
| Printer Type | Label printer - direct thermal / thermal transfer |
| Weight | 40.56 lbs |
| Max Media Size | Roll (149.6 cm) |
| Min Media Size (Custom) | 21.4 mm |
| Max Media Size (Custom) | 1496 mm |
| Print Speed | Up to 720.5 inch/min - max speed |
| Max Resolution (B&W) | 203 dpi |
| Interface | USB 2.0, USB host, Gigabit LAN |
| Processor | 1 GHz |
| RAM Installed (Max) | 1 GB |
| Flash Memory Installed (Max) | 8 GB |
| Language Simulation | TPCL, DPL, SBPL, Intermec Printer Language (IPL), ZPL II, PDF |
| Barcodes | EAN/JAN-8, EAN/JAN-13, UPC-A / E, NW-7, Code 39, Code 93, ITF, MSI, Code 128, EAN-128, Industrial 2 of 5, Postnet, RM4SCC, Kix (Netherlands) Post, GS1 DataBar, USPS Intelligent Mail, Data Matrix, PDF417, MaxiCode, QR code, Micro QR code, MicroPDF417, CP code, Aztec, GS1 QR code, GS1 DataMatrix |
| Media Type | Fanfold paper, label roll |
| Fonts | Bitmap, Outline, Price, Downloadable TTF, OTF |
| Features | Reflective media sensor, transmissive media sensor, ribbon end sensor |
| Keyboard | 11 keys |
| Networking | Print server |
| Printer Features | Flat head |
| Power | AC 100-240 V |
| System Requirements | Microsoft Windows Server 2019, Microsoft Windows Server 2022, Microsoft Windows 10 / 11, SAP, Apple MacOS |
| Dimensions (WxDxH) | 13 in x 18.1 in x 12.2 in |
| General | |
| Printer Type | Label printer - direct thermal / thermal transfer |
| Expansion / Connectivity | |
| Connections | 1 x USB 2.0 ¦ 1 x Gigabit LAN - RJ-45 ¦ 2 x USB host - 4 pin USB Type A |
| Printer | |
| Print Speed | Up to 720.5 inch/min - max speed - 203 dpi |
| Built-in Devices | 4.3 inch LCD display |
| Connectivity Technology | Wired |
| Interface | USB 2.0, USB host, Gigabit LAN |
| Max Resolution (B&W) | 203 dpi |
| Language Simulation | TPCL, DPL, SBPL, Intermec Printer Language (IPL), ZPL II, PDF |
| Fonts | Bitmap, Outline, Price, Downloadable TTF, OTF |
| Features | Reflective media sensor, transmissive media sensor, ribbon end sensor |
| Keyboard | 11 keys |
| Barcodes | EAN/JAN-8, EAN/JAN-13, UPC-A / E, NW-7, Code 39, Code 93, ITF, MSI, Code 128, EAN-128, Industrial 2 of 5, Postnet, RM4SCC, Kix (Netherlands) Post, GS1 DataBar, USPS Intelligent Mail, Data Matrix, PDF417, MaxiCode, QR code, Micro QR code, MicroPDF417, CP code, Aztec, GS1 QR code, GS1 DataMatrix |
| Printer Features | Flat head |
| Processor | |
| Processor | 1 GHz |
| RAM | |
| RAM Installed (Max) | 1 GB |
| Media Handling | |
| Media Type | Fanfold paper, label roll |
| Max Media Size | Roll (149.6 cm) |
| Min Media Size (Custom) | 21.4 mm |
| Max Media Size (Custom) | 1496 mm |
| Media Sizes | Roll (149.6 cm) |
| Max Printing Width | 6.38 in |
| Max Printing Length | 58.9 in |
| Media Thickness Range | 0.0051 in - 0.0067 in |
| Roll Maximum Outer Diameter | 7.9 in |
| Roll Core Diameter | 3 in |
| Media Feeders | 1 x manual - 1 roll - Roll (149.6 cm) |
| Networking | |
| Networking | Print server |
| Power | |
| Power Device | Power adapter - external |
| Voltage Required | AC 100-240 V |
| Frequency Required | 50/60 Hz |
| Software / System Requirements | |
| Software Included | Bartender UltraLite |
| OS Required | Microsoft Windows Server 2019, Microsoft Windows Server 2022, Microsoft Windows 10 / 11, SAP, Apple MacOS |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 25 - 85% RH (non-condensing) |
| Flash Memory | |
| Flash Memory | 8 GB |
| Dimensions & Weight | |
| Width | 13 in |
| Depth | 18.1 in |
| Height | 12.2 in |
| Weight | 40.56 lbs |
