X-Series - wireless network management device - 1GbE, Wi-Fi 7, Bluetooth 5.4 LE - Wi-Fi 7, Bluetooth - 2.4 GHz, 5 GHz, 6 GHz - wall mountable
| Main Specifications | |
|---|---|
| Product Description | HPE Aruba Networking User Experience Insight Wi-Fi 7 Ethernet Sensor - X-Series - wireless network management device - Wi-Fi 7, Bluetooth |
| Device Type | Wireless network management device |
| Form Factor | Wall mountable |
| Data Link Protocol | Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11be (Wi-Fi 7), Bluetooth 5.4 LE |
| Frequency Band | 2.4 GHz, 5 GHz, 6 GHz |
| Included Accessories | Mounting bracket, mounting screws, rubber feet |
| Power Over Ethernet (PoE) Supported | PoE |
| Dimensions (WxDxH) | 3.3 in x 2 in x 11.8 in |
| Weight | 22.11 oz |
| Manufacturer Warranty | 1-year warranty |
| General | |
| Device Type | Wireless network management device |
| Width | 3.3 in |
| Depth | 2 in |
| Height | 11.8 in |
| Weight | 22.11 oz |
| Expansion / Connectivity | |
| Interfaces | 1 x 10/100/1000Base-T - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - replacement - 1 year ¦ Limited warranty - shipping - 10 days ¦ Technical support - software application support - 1 year |
| Miscellaneous | |
| Included Accessories | Mounting bracket, mounting screws, rubber feet |
| MTBF | 1.629.079 hours |
| Compliant Standards | RED 2014/53/EU, UL 62368, IEC 62368, EN 62368, FCC-ID, UL 2043 |
| Networking | |
| Form Factor | Wall mountable |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11be (Wi-Fi 7), Bluetooth 5.4 LE |
| Frequency Band | 2.4 GHz, 5 GHz, 6 GHz |
| Features | Bluetooth (BLE) clients support, security slot (Kensington security lock compatible), Multi-Link Operation (MLO), QOS enhanced basic service set (QBSS), off-band monitoring, Low Power Indoor (LPI) support, Standard Power (SP) support |
| Encryption Algorithm | WPA2-PSK, WPA2-SAE, WPA2-Enterprise, OWE, WPA3-Enterprise, EAP-LEAP, EAP-PEAP, EAP-TTLS |
| Compliant Standards | IEEE 802.3af |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE |
| Power Device | External power adapter (not included) |
| Power Consumption Operational | 12 watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 - 93% (non-condensing) |
