Battery enclosure (rack-mountable / external) - 208V - AC 200/208/220/230/240 V - 8000 VA - lithium ion - 12 Ah - 2304 Wh - output connectors: 2 - 4U
| Main Specifications | |
|---|---|
| Product Description | Eaton 9PX - battery enclosure - 208V - 8000 VA - Li-Ion - 12 Ah - 2304 Wh |
| Device Type | Battery enclosure - rack-mountable / external |
| Rack Size | 4U |
| Weight | 132.28 lbs |
| Input Voltage | AC 200/208/220/230/240 V |
| Output Voltage | AC 200/208/220/230/240 V |
| Power Capacity | 8000 VA |
| Input Connectors | Hardwire |
| Output connectors | 1 x hardwire ¦ 4 x power NEMA L6-30R |
| Battery | Lithium ion - 12 Ah - 2304 Wh |
| Dimensions (WxDxH) | 17.3 in x 28.6 in x 6.8 in |
| Environmental Standards | ENERGY STAR |
| Manufacturer Warranty | 5-year warranty |
| General | |
| Device Type | Battery enclosure - rack-mountable / external |
| Height (Rack Units) | 4U |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Features | Single-phase, daisy chaining support, Battery Management System (BMS), LCD display, audible alarm, built-in cooling fan, double conversion, pure sinewave output |
| Compliant Standards | cUL, EN 62040-2, FCC (USA), Mexico NOM, RoHS |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Battery | |
| Technology | Lithium ion |
| Voltage Provided | 192 V |
| Capacity | 12 Ah - 2304 Wh |
| Features | Hot-swappable |
| Power Device | |
| UPS Technology | On-line |
| Input Voltage | AC 200/208/220/230/240 V |
| Frequency Provided | 50/60 Hz |
| Input Connectors | Hardwire |
| Power Output Connectors Details | 1 x hardwire ¦ 4 x power NEMA L6-30R |
| Output Voltage | AC 200/208/220/230/240 V 50/60 Hz |
| Power Capacity | 8000 VA |
| Power Factor (PF) | 1.0 |
| Dimensions & Weight | |
| Width | 17.3 in |
| Depth | 28.6 in |
| Height | 6.8 in |
| Weight | 132.28 lbs |
| Sustainability Information | |
| ENERGY STAR | Yes |
