Wireless router - 3G, 4G - panel-mountable, DIN rail mountable
| Main Specifications | |
|---|---|
| Product Description | InHand InRouter302 - wireless router - Wi-Fi - 3G, 4G - panel-mountable, DIN rail mountable |
| Device Type | Wireless router |
| Enclosure Type | Panel-mountable, DIN rail mountable |
| Cellular Protocol | LTE Cat4, FDD LTE, WCDMA |
| Generation | 3G, 4G |
| Cellular Band | LTE B2, LTE B12, LTE B4, LTE B5, LTE B13, LTE B14, LTE B66, LTE B71, WCDMA B2, WCDMA B4, WCDMA B5 |
| WAN Ports Qty | 1 |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Fast Ethernet, Ethernet |
| Data Transfer Rate | 150 Mbps |
| Network / Transport Protocol | ARP, PPPoE, DHCP, DDNS, Telnet, PPTP, L2TP, IPSec, OpenVPN |
| Routing Protocol | Static IP routing, GRE |
| Remote Management Protocol | SNMP 1, SNMP 2c, SNMP 3 |
| Features | Reset button, ground points, over-current protection, metal housing, fanless, APN management, multiple PDN, PPP, DHCP server, DHCP relay, DHCP client, DNS relay, NAT support, SPI, DoS attack prevention, ACL support, IP-MAC binding, Multicast filtering function, port mapping, URL filtering, VIP, CA, VRRP support, hardware watchdog, PSK, QoS, SNMP trap, traffic management |
| Power | DC 9 - 36 V |
| Dimensions (WxDxH) | 3.5 in x 3.5 in x 1 in |
| Weight | 8.46 oz |
| Localization | North America |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Wireless router |
| Enclosure Type | Panel-mountable, DIN rail mountable |
| Connectivity Technology | Wired, wireless |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Fast Ethernet, Ethernet |
| Data Transfer Rate | 150 Mbps |
| Network / Transport Protocol | ARP, PPPoE, DHCP, DDNS, Telnet, PPTP, L2TP, IPSec, OpenVPN |
| Routing Protocol | Static IP routing, GRE |
| Remote Management Protocol | SNMP 1, SNMP 2c, SNMP 3 |
| Encryption Algorithm | IKEv1, IKEv2, WPA, WPA2, WEP, TKIP, AES |
| Authentication Method | CHAP, PAP, Secure Shell (SSH) |
| Features | Reset button, ground points, over-current protection, metal housing, fanless, APN management, multiple PDN, PPP, DHCP server, DHCP relay, DHCP client, DNS relay, NAT support, SPI, DoS attack prevention, ACL support, IP-MAC binding, Multicast filtering function, port mapping, URL filtering, VIP, CA, VRRP support, hardware watchdog, PSK, QoS, SNMP trap, traffic management |
| Compliant Standards | IP30, EN 61000-4-2, EN 61000-4-3, EN 61000-4-12, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, IEC 60068-2-27, IEC 60068-2-32, IEC 60068-2-6, FCC, PTCRB, IC |
| Processor | 580 MHz |
| RAM | 128 MB DDR2 SDRAM |
| Status Indicators | Power, status, cellular, Wi-Fi, signal strength |
| Expansion / Connectivity | |
| Interfaces | WAN / LAN: 1 x Ethernet 10/100 - RJ-45 ¦ LAN: 1 x Ethernet 10/100 - RJ-45 ¦ Antenna: 2 x SMA - LTE ¦ Antenna: 1 x RP-SMA - Wi-Fi |
| Expansion Slots | 2 (total) / 2 (free) x Mini-SIM |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Localization | North America |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | DC 9 - 36 V |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 158 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Communications | |
| Cellular Protocol | LTE Cat4, FDD LTE, WCDMA |
| Generation | 3G, 4G |
| Cellular Band | LTE B2, LTE B12, LTE B4, LTE B5, LTE B13, LTE B14, LTE B66, LTE B71, WCDMA B2, WCDMA B4, WCDMA B5 |
| Dimensions & Weight | |
| Width | 3.5 in |
| Depth | 3.5 in |
| Height | 1 in |
| Weight | 8.46 oz |
