86" Diagonal Class LED-backlit LCD display - interactive - with touchscreen (multi touch) / 8-microphone array / optional slot-in PC capability - 4K UHD (2160p) 3840 x 2160 - Direct LED - B2B - with ViewSonic VB-WIFI-004 Adapter
| Main Specifications | |
|---|---|
| Product Description | ViewSonic ViewBoard IFP8641 86" LED-backlit LCD display - 4K - for interactive communication |
| Product Type | LED-backlit LCD flat panel display with touchscreen (multi touch) / 8-microphone array / optional slot-in PC capability |
| Diagonal Class | 86" |
| Commercial Use | Yes - interactive |
| Bundled with | ViewSonic VB-WIFI-004 Adapter |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| Video Interface | HDMI |
| HDMI Ports Qty | 3 ports |
| Connectivity | Wi-Fi, LAN, Bluetooth |
| PC Interface | VGA (HD-15), DisplayPort, USB-C |
| LCD Backlight Technology | Direct LED |
| Image Aspect Ratio | 16:9 |
| TV Tuner | No tuner |
| Commercial Features | ViewSonic Manager Software |
| Speaker System | 2 speakers, sound bar |
| Storage Capacity | 128 GB eMMC |
| USB | Yes |
| Included Accessories | Remote control, 2 styluses, 4 screws, camera plate, 5 clamps, RS232 adapter |
| Voltage | AC 100-240 V |
| Power Consumption Stand by | 0.5 watt |
| Dimensions (WxDxH) | 77 in x 3.4 in x 46.1 in |
| Weight | 128.31 lbs |
| Pricing Type | B2B |
| Environmental Standards | ENERGY STAR Qualified, EPEAT Silver |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Diagonal Class | 86" |
| Commercial Use | Yes - interactive |
| Bundled with | ViewSonic VB-WIFI-004 Adapter |
| Combined With | Touchscreen (multi touch) / 8-microphone array / optional slot-in PC capability |
| Operating System | Android OS 16 |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI |
| HDMI Ports Qty | 3 ports |
| PC Interface | VGA (HD-15), DisplayPort, USB-C |
| Width | 77 in |
| Depth | 3.4 in |
| Height | 46.1 in |
| Weight | 128.31 lbs |
| Pricing Type | B2B |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years - on-site ¦ Limited warranty - backlight - 3 years - on-site |
| Miscellaneous | |
| Included Accessories | 2 styluses, 4 screws, camera plate, 5 clamps, RS232 adapter |
| Cables Included | USB-C cable - 6 ft ¦ USB touch cable - 10 ft ¦ HDMI cable - 10 ft |
| Compliant Standards | FCC, RoHS, cTUVus, CEC, Google EDLA |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V |
| Power Consumption Stand by | 0.5 watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 80% (non-condensing) |
| Display | |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Image Aspect Ratio | 16:9 |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| LCD Backlight Technology | Direct LED |
| Coating | Anti-glare, 3.2 mm glass, 9H hardness |
| Image Contrast Ratio | 5000:1 |
| Dynamic Contrast Ratio | 5000:1 |
| Brightness | 350 cd/m² |
| Viewing Angle | 178 |
| Viewing Angle (Vertical) | 178 |
| Touchpoints Qty | 64 |
| Response Time | 8 ms |
| Backlight Life | 50,000 hours |
| Commercial Features | ViewSonic Manager Software |
| Additional Features | Infrared multitouch technology, Open Pluggable Specification slot, Palm Rejection, 5ms latency |
| Connections | |
| Connector Type | 3 x HDMI input ¦ HDMI output ¦ VGA input ¦ DisplayPort input ¦ 2 x USB-C with 100W Power Delivery ¦ 5 x USB ¦ 3 x USB ¦ RS-232 ¦ 2 x Gigabit LAN ¦ Audio input ¦ SPDIF output |
| Remote Control | |
| Type | Remote control |
| Battery Form Factor | AAA type |
| Battery Included | Yes |
| Audio System | |
| Speaker System | 2 speakers, sound bar |
| Output Power / Total | 55 watt |
| Additional Features | 8 x beam-forming microphone array, full duplex echo cancellation, Immersive Audio |
| Speakers | 2 x main channel speaker - 20 watt ¦ 1 x sound bar - 15 watt |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 82.7 in |
| Depth (Shipping) | 6.9 in |
| Height (Shipping) | 50.9 in |
| Weight (Shipping) | 160.72 lbs |
| Network & Internet Multimedia | |
| Connectivity | Wi-Fi, LAN, Bluetooth |
| LAN Protocol | Gigabit Ethernet |
| Wi-Fi Protocol | 802.11b, 802.11g, 802.11n, 802.11a, 802.11ac, 802.11ax |
| Bluetooth Version | Bluetooth 5.0 |
| Stands & Mounts | |
| Flat Panel Mount Interface | 800 x 600 mm |
| VESA Compatibility | Yes |
| Media Player | |
| USB Port | Yes |
| Configuration | Rockchip RK3576 - 8 GB LPDDR - 128 GB eMMC |
| Sustainability Information | |
| EPEAT Compliant | EPEAT Silver |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 8.0 |
