UPS - AC 120 V - 550 Watt - 900 VA - output connectors: 8
| Main Specifications | |
|---|---|
| Product Description | Vertiv PowerUPS 100 Standby Series PST6-900LVMT - UPS - 550 Watt - 900 VA |
| Device Type | UPS - external |
| Weight | 9.7 lbs |
| Input Voltage | AC 120 V |
| Output Voltage | AC 120 V |
| Power Capacity | 550 Watt / 900 VA |
| Input Connectors | 1 x power NEMA 5-15R |
| Output connectors | 8 x power NEMA 5-15R (surge) - 120 V |
| Battery | Lead acid |
| Batteries Qty | 1 |
| Run Time (Up To) | 8.2 min at half load |
| Dimensions (WxDxH) | 4.7 in x 8.3 in x 5.5 in |
| Environmental Standards | ENERGY STAR |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | UPS - external |
| Expansion / Connectivity | |
| Interfaces | 1 x USB - 4 pin USB Type A ¦ 2 x USB - 24 pin USB-C |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Cables Included | Power cable 6 ft ¦ USB-A to USB-B cable |
| Equipment Protection Value | 300000 US Dollars |
| Features | Wall mountable, LED indicators, user-replaceable batteries, Extended Power Performance (EPP), overcurrent protection, short-circuit protection, overcharge protection |
| Compliant Standards | cTUVus, UL 1778, CSA 2.2 No.1073:2014, FCC Part 15 B, ANSI C62.41, Energy Star 2.0, DOE, ISTA 3A |
| Software / System Requirements | |
| Software Included | Vertiv Power Assist |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 90% (non-condensing) |
| Sound Emission | 45 dB |
| Battery | |
| Quantity | 1 |
| Technology | Lead acid |
| Transfer Time | 10 ms |
| Features | Sealed, valve-regulated |
| Power Device | |
| Input Voltage | AC 120 V |
| Input Voltage Range | AC 88 - 142 V |
| Frequency Provided | 50/60 Hz ± 1 Hz |
| Frequency Required | 50/60 Hz ± 5Hz |
| Input Connectors | 1 x power NEMA 5-15R |
| Power Output Connectors Details | 8 x power NEMA 5-15R (surge) - 120 V |
| Output Voltage | AC 120 V 50/60 Hz |
| Power Capacity | 550 Watt / 900 VA |
| Output Waveform | Simulated sine wave |
| Surge Energy Rating | 500 Joules |
| Circuit Protection | Circuit breaker |
| Efficiency | 95% at 100% Load |
| Dimensions & Weight | |
| Width | 4.7 in |
| Depth | 8.3 in |
| Height | 5.5 in |
| Weight | 9.7 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 11.1 in |
| Shipping Depth | 15.5 in |
| Shipping Height | 7.7 in |
| Sustainability Information | |
| ENERGY STAR | Yes |
