QSFP28 transceiver module - 100GbE - 100GBase-PSM4 - MPO-12/APC single-mode - up to 1.2 miles - 1310 (TX) / 1310 (RX) nm
| Main Specifications | |
|---|---|
| Product Description | Ubiquiti UniFi - QSFP28 transceiver module - 100GbE |
| Device Type | QSFP28 transceiver module - MPO-12/APC single-mode |
| Form Factor | Plug-in module |
| Cabling Type | 100GBase-PSM4 |
| Data Transfer Rate | 100 Gbps |
| Optical Wave Length | 1310 (TX) / 1310 (RX) nm |
| Data Link Protocol | 100GbE |
| Max Transfer Distance | 1.2 miles |
| General | |
| Device Type | QSFP28 transceiver module |
| Form Factor | Plug-in module |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 100GBase-PSM4 - MPO-12/APC single-mode |
| Miscellaneous | |
| Compliant Standards | Laser Class 1, EN 60825-1:2014, RCM, UKCA, WEEE |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 100GBase-PSM4 |
| Data Link Protocol | 100GbE |
| Data Transfer Rate | 100 Gbps |
| Optical Wave Length | 1310 (TX) / 1310 (RX) nm |
| Max Transfer Distance | 1.2 miles |
| Power | |
| Power Consumption Operational | 3.5 watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 158 °F |
