85" Diagonal Class (84.5" viewable) - SMHX Series 3D LED-backlit LCD display - spatial signage - Tizen OS - 4K UHD (2160p) 3840 x 2160 - black
| Main Specifications | |
|---|---|
| Product Description | Samsung SM85HX SMHX Series - 85" Class (84.5" viewable) LED-backlit LCD display - 4K - for spatial signage |
| Product Type | LED-backlit LCD flat panel display |
| Diagonal Class | 85" |
| Diagonal Size | 84.5" |
| Commercial Use | Yes - spatial signage |
| Color | Black |
| 3D | Yes |
| 3D Technology | Glasses-free |
| Platform | Tizen OS |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Video Interface | HDMI |
| HDMI Ports Qty | 3 ports |
| Connectivity | Wi-Fi, LAN, Bluetooth |
| PC Interface | DisplayPort |
| Technology | VA |
| LCD Backlight Technology | LED backlight |
| Image Aspect Ratio | 9:16 |
| TV Tuner | No tuner |
| Commercial Features | SMART Signage Platform, Samsung VXT CMS, MagicInfo S10 Player, Signage New Home, Microsoft 365, Custom Home, Auto Source Switching & Recovery, upgradable web-engine, Tizen Enterprise Platform, HDR support |
| Picture Enhancements | 72% Color Gamut NTSC, Intelligent UHD upscaling |
| Speaker System | 2 channel |
| Platform | SmartThings Pro |
| Storage Capacity | 16 GB (available 10 GB) |
| USB | 2 ports |
| Included Accessories | Remote control |
| Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 340 Watt |
| Dimensions (WxDxH) - without stand | 43.4 in x 2 in x 75.6 in |
| Weight | 108.03 lbs |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Power Consumption (Max) | 484 Watt |
| Power Consumption Operational | 340 Watt |
| Diagonal Class | 85" |
| Diagonal Size | 84.5" |
| Commercial Use | Yes - spatial signage |
| Series | SMHX Series |
| 3D | Yes |
| 3D Technology | Glasses-free |
| Platform | Tizen OS |
| Operating System | Tizen OS 7.0 |
| Video Processor | Quantum 4K |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Sensors | Ambient light sensor (ALS), temperature sensor |
| Video Interface | HDMI |
| HDMI Ports Qty | 3 ports |
| PC Interface | DisplayPort |
| Modes | Portrait mode |
| Picture Enhancements | 72% Color Gamut NTSC, Intelligent UHD upscaling |
| Design | UltraThin |
| Dimensions | Without stand |
| Width | 43.4 in |
| Depth | 2 in |
| Height | 75.6 in |
| Weight | 108.03 lbs |
| Enclosure Color | Black |
| Miscellaneous | |
| Cables Included | RS-232C (IN) adapter |
| Compliant Standards | EMC Class A, Safety 60950-1, Safety 62368-1, IP5X |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Sleep | 0.5 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 80% |
| Display | |
| LCD Display Technology | VA |
| Pixel Pitch | 0.487 mm |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Image Aspect Ratio | 9:16 |
| LCD Backlight Technology | LED backlight |
| Coating | Anti-glare, 25% Glass Haze |
| Image Contrast Ratio | 4000:1 |
| Brightness | 500 cd/m² |
| Commercial Features | SMART Signage Platform, Samsung VXT CMS, MagicInfo S10 Player, Signage New Home, Microsoft 365, Custom Home, Auto Source Switching & Recovery, upgradable web-engine, Tizen Enterprise Platform, HDR support |
| Operation Hours / Days | 24 / 7 |
| Additional Features | SSSP 10.0, Center IR, Workspace, True 3D Enhancer, 3D plate technology, Virtual 3D display, Virtual 3D Spatial Effect |
| Connections | |
| Connector Type | 3 x HDMI input ¦ DisplayPort input ¦ 2 x USB 2.0 ¦ Audio line-out ¦ RS-232 input ¦ RS-232 output ¦ LAN input |
| Remote Control | |
| Type | Remote control |
| Battery Included | Yes |
| Audio System | |
| Speaker System | 2 channel |
| Output Power / Total | 10 Watt |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 82.4 in |
| Depth (Shipping) | 8.7 in |
| Height (Shipping) | 48.6 in |
| Weight (Shipping) | 136.46 lbs |
| Network & Internet Multimedia | |
| Connectivity | Wi-Fi, LAN, Bluetooth |
| LAN Protocol | Ethernet |
| Encryption | EAP-PEAP, EAP-TLS, EAP-TTLS, WPA2-Enterprise, WPA3-Personal |
| Stands & Mounts | |
| Flat Panel Mount Interface | 400 x 600 mm |
| VESA Compatibility | Yes |
| Media Player | |
| USB Port | Yes |
| USB Ports Qty | 2 |
| Configuration | ARM Cortex-A73 Quad-Core ( 1.6 GHz ) 16 GB (available 10 GB) |
| Internet of Things (IoT) | |
| Internet of Things (IoT) Compatible | Yes |
| Platform | SmartThings Pro |
