Gen 2 - wireless video/audio extender - Wi-Fi 5, 10Mb LAN - with administrative tools
| Main Specifications | |
|---|---|
| Product Description | ScreenBeam 1000 EDU - Gen 2 - wireless video/audio extender - Wi-Fi 5, 10Mb LAN |
| Device Type | Wireless video/audio extender |
| Bundled with | Administrative tools |
| Form Factor | External |
| Data Link Protocol | Wi-Fi 5, 10Mb LAN |
| Power | DC 12 V |
| System Requirements | Microsoft Windows 10 / 11, Android 8.0 (Oreo) or later, Apple macOS 11, Apple iOS 13 or later, Google Chrome OS |
| Dimensions (WxDxH) | 8.7 in x 5.7 in x 1.5 in |
| Weight | 15.99 oz |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Wireless video/audio extender |
| Bundled with | Administrative tools |
| Form Factor | External |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 1000Base-T - RJ-45 ¦ 1 x HDMI (output) - 19 pin HDMI Type A ¦ 1 x USB 3.0 - Type A ¦ 2 x USB 2.0 - Type A ¦ 1 x audio - mini jack |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | Magnetic mounting kit |
| Cables Included | HDMI cable |
| Compliant Standards | FCC, UL, RED, RoHS |
| Networking | |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Wi-Fi 5, 10Mb LAN |
| Max Resolution | 4K @ 30 Hz |
| Features | Interactive whiteboard function, extend mode, Wi-Fi Miracast ready, Apple AirPlay, Google Cast, LPCM 2.0 support, HDCP compliant, 3x3 MIMO technology, 2x2 MIMO 2.4GHz, 2x2 MIMO 5GHz, screen mirroring, 802.1x authentication, 4K/30 resolution support, H.264 video codec, ScreenBeam Ghost Inking technology |
| Encryption Algorithm | WPA-PSK, TKIP, WPA2-PSK, AES, PEAP, EAP-TLS |
| Authentication Method | MS-CHAP v.2 |
| Compliant Standards | IEEE 802.11ac, IEEE 802.1x |
| Power | |
| Power Device | External power adapter |
| Voltage Required | DC 12 V |
| Power Consumption Operational | 8.4 watt |
| Software / System Requirements | |
| OS Required | Microsoft Windows 10 / 11, Android 8.0 (Oreo) or later, Apple macOS 11, Apple iOS 13 or later, Google Chrome OS |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 80% (non-condensing) |
| Dimensions & Weight | |
| Width | 8.7 in |
| Depth | 5.7 in |
| Height | 1.5 in |
| Weight | 15.99 oz |
