Label printer - direct thermal / thermal transfer - - 300 dpi - up to 720.5 inch/min - USB 2.0, LAN, USB host, serial, Wi-Fi(n), Bluetooth 5.0 - with 2 years Premier Limited Warranty
| Main Specifications | |
|---|---|
| Product Description | Brother TJ-4522TN - label printer - B/W - direct thermal / thermal transfer |
| Printer Type | Label printer - direct thermal / thermal transfer - B/W |
| Bundled Services | 2 years Premier Limited Warranty |
| Weight | 41.73 lbs |
| Max Media Size | Roll (4.5 in) |
| Min Media Size (Custom) | 8 in |
| Max Media Size (Custom) | 4.5 in |
| Print Speed | Up to 720.5 inch/min - max speed |
| Max Resolution (B&W) | 300 dpi |
| Interface | USB 2.0, LAN, USB host, serial, Wi-Fi(n), Bluetooth 5.0 |
| RAM Installed (Max) | 256 MB |
| Flash Memory Installed (Max) | 512 MB |
| Language Simulation | FBPL, ZPL II, EPL2, DPL |
| Barcodes | Code 93, Code 39, Code 49, Code 128C, Code 128A, Code 128B, Interleaved 2 of 5, Industrial 2 of 5, EAN-13, EAN-8, UPC-A, UPC-E, Codabar, Postnet, MSI, Plessey, China Post, ITF-14, EAN-14, Code 11, Telepen, PLANET, Deutsche Post Identcode, Deutsche Post Leitcode, LOGMARS, Codablock F, GS1 DataBar, GS1 DataMatrix, MaxiCode, Aztec code, PDF417, QR code, MicroPDF417, TLC39 |
| Media Type | Continuous labels |
| Features | Label detection sensor, gap sensor, open head sensor, reflective/black mark sensor, ribbon encode sensor, ribbon end sensor |
| Networking | Print server |
| Power | AC 100-240 V |
| System Requirements | Microsoft Windows 7 (32/64 bits), Windows 10 (32/64 bits), Windows 8 (32/64 bits), Android 2.2 or later, Apple iOS 6.0 or later, Apple MacOS X 10.10.x or later, Debian Linux, Red Hat Linux |
| Dimensions (WxDxH) | 10.9 in x 19.8 in x 16.2 in |
| General | |
| Printer Type | Label printer - direct thermal / thermal transfer - monochrome |
| Bundled Services | 2 years Premier Limited Warranty |
| Expansion / Connectivity | |
| Connections | 1 x serial ¦ 1 x USB 2.0 ¦ 1 x LAN - RJ-45 ¦ 1 x USB host |
| Miscellaneous | |
| Cables Included | 1 x USB cable |
| Printer | |
| Print Speed | Up to 720.5 inch/min - max speed |
| Built-in Devices | 3.5 inch LCD display |
| Connectivity Technology | Wireless |
| Interface | USB 2.0, LAN, USB host, serial, Wi-Fi(n), Bluetooth 5.0 |
| Max Resolution (B&W) | 300 dpi |
| Language Simulation | FBPL, ZPL II, EPL2, DPL |
| Features | Label detection sensor, gap sensor, open head sensor, reflective/black mark sensor, ribbon encode sensor, ribbon end sensor |
| Barcodes | Code 93, Code 39, Code 49, Code 128C, Code 128A, Code 128B, Interleaved 2 of 5, Industrial 2 of 5, EAN-13, EAN-8, UPC-A, UPC-E, Codabar, Postnet, MSI, Plessey, China Post, ITF-14, EAN-14, Code 11, Telepen, PLANET, Deutsche Post Identcode, Deutsche Post Leitcode, LOGMARS, Codablock F, GS1 DataBar, GS1 DataMatrix, MaxiCode, Aztec code, PDF417, QR code, MicroPDF417, TLC39 |
| RAM | |
| RAM Installed (Max) | 256 MB |
| Media Handling | |
| Media Type | Continuous labels |
| Max Media Size | Roll (4.5 in) |
| Min Media Size (Custom) | 8 in |
| Max Media Size (Custom) | 4.5 in |
| Media Sizes | Roll (4.5 in) |
| Max Printing Width | 4.09 in |
| Max Printing Length | 450 in |
| Media Thickness Range | 0.0024 in - 0.01 in |
| Networking | |
| Networking | Print server |
| Remote Management Protocol | SNMP 1, Telnet |
| Security Protocols & Features | ARP, 802.1x |
| Power | |
| Power Device | Power supply - internal |
| Voltage Required | AC 100-240 V |
| Frequency Required | 50/60 Hz |
| Software / System Requirements | |
| OS Required | Microsoft Windows 7 (32/64 bits), Windows 10 (32/64 bits), Windows 8 (32/64 bits), Android 2.2 or later, Apple iOS 6.0 or later, Apple MacOS X 10.10.x or later, Debian Linux, Red Hat Linux |
| Flash Memory | |
| Flash Memory | 512 MB |
| Dimensions & Weight | |
| Width | 10.9 in |
| Depth | 19.8 in |
| Height | 16.2 in |
| Weight | 41.73 lbs |
| Environmental Standards | |
| ENERGY STAR | Yes |
| ENERGY STAR Version | 3.0 |
