MPF Series LED display unit - digital signage 36" 480 x 270 per unit - Flip-chip RGB LED - HDR
| Main Specifications | |
|---|---|
| Product Description | Samsung The Wall MP016F MPF Series LED display unit - for digital signage |
| Product Type | LED display unit |
| Commercial Use | Yes - digital signage |
| HDR Format | HDR10, HDR10+ |
| HDR Technology | LED HDR, Micro HDR |
| Frame Rate & Enhancement Technology | 100 Hz Video Rate, 120 Hz Video Rate, 120 Hz Refresh Rate, 3840 Hz Refresh Rate, 7680 Hz Refresh Rate |
| TV Tuner | No tuner |
| Commercial Features | MagicInfo compatible |
| Picture Enhancements | AI Picture, Dynamic Peaking Technology, Linear Grayscale, Black Seal Technology+ |
| Video Wall Display Unit | 36" - Flip-chip RGB LED - 480 x 270 |
| Voltage | AC 100-240 V (50/60 Hz) |
| Dimensions (WxDxH) - cabinet | 31.7 in x 1.9 in x 17.9 in |
| Weight | 20.28 lbs |
| General | |
| Product Type | LED display unit |
| Commercial Use | Yes - digital signage |
| Series | MPF Series |
| HDR Capable | Yes |
| HDR Format | HDR10, HDR10+ |
| HDR Technology | LED HDR, Micro HDR |
| Video Processor | NQM AI Gen 2 |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Sensors | Temperature sensor |
| Picture Enhancements | AI Picture, Dynamic Peaking Technology, Linear Grayscale, Black Seal Technology+ |
| Design | One-Body design |
| Dimensions | Cabinet |
| Width | 31.7 in |
| Depth | 1.9 in |
| Height | 17.9 in |
| Weight | 20.28 lbs |
| Miscellaneous | |
| Compliant Standards | IP40 front, IP20 rear, Safety 60950-1, Safety 62368-1, EMC Class B, Pantone Validated, Pantone Skintone Validated, TUV Low Grayscale Image Clarity certified, Color Consistency for Wide Viewing Angle certified, TUV Eye Comfort certified |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Video Wall Display Unit Power Consumption (Max) | 161 W |
| Video Wall Display Unit Power Consumption (Typical) | 68 W |
| Video Wall Power Consumption (Max) | 440 W/m² |
| Video Wall Power Consumption (Typical) | 186 W/m² |
| Heat Generation Details | Cabinet - max - 549 BTU ¦ Video wall - max - 1502 BTU/m² ¦ Cabinet - typical - 262 BTU ¦ Video wall - typical - 634 BTU/m² |
| Features | Power Redundancy |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 80% RH |
| Display | |
| Frame Rate & Enhancement Technology | 100 Hz Video Rate, 120 Hz Video Rate, 120 Hz Refresh Rate, 3840 Hz Refresh Rate, 7680 Hz Refresh Rate |
| Color Temperature | 2800 - 10000K |
| Image Contrast Ratio | 43000:1 |
| Brightness | 1600 cd/m² |
| Viewing Angle | 170° |
| Viewing Angle (Vertical) | 155° |
| Commercial Features | MagicInfo compatible |
| Additional Features | 16-bit support, 20-bit processing, SNOW-AAE controller |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 35.7 in |
| Depth (Shipping) | 21.5 in |
| Height (Shipping) | 7 in |
| Weight (Shipping) | 27.78 lbs |
| Network & Internet Multimedia | |
| Connect & Share | Multi View |
| Video Wall Display Unit | |
| Pixel Pitch | 1.68 mm |
| Pixel Configuration | 1 red, 1 green, 1 blue |
| LED Type | Flip-chip RGB LED |
| Resolution | 480 x 270 |
| LED Lifetime | 150000 hours |
| Maintenance | Front |
| Cabinet Diagonal Size | 36" |
| Modules Configuration (Per Cabinet) | 4x3 |
