85" Diagonal Class LED-backlit LCD display - digital signage - 4K UHD (2160p) 3840 x 2160 - black
| Main Specifications | |
|---|---|
| Product Description | TCL TM85N 85" LED-backlit LCD display - 4K - for digital signage |
| Product Type | LED-backlit LCD flat panel display |
| Diagonal Class | 85" |
| Commercial Use | Yes - digital signage |
| Color | Black |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| Video Interface | HDMI |
| HDMI Ports Qty | 2 ports |
| Connectivity | Bluetooth, LAN, Wi-Fi |
| PC Interface | DisplayPort |
| Technology | VA |
| LCD Backlight Technology | E-LED backlight |
| Image Aspect Ratio | 16:9 |
| TV Tuner | No tuner |
| Commercial Features | Security lock, Image Rotation |
| Picture Enhancements | 93% DCI-P3 color gamut, Pixel Shift |
| Speaker System | 2 speakers |
| Storage Capacity | 32 GB |
| USB | 2 ports |
| Included Accessories | Remote control, 2 power cables |
| Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 185 Watt |
| Power Consumption Stand by | 0.5 Watt |
| Dimensions (WxDxH) | 74.8 in x 1.3 in x 42.5 in |
| Weight | 97 lbs |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Power Consumption Operational | 185 Watt |
| Diagonal Class | 85" |
| Commercial Use | Yes - digital signage |
| Operating System | Android OS 13.0 |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI |
| HDMI Ports Qty | 2 ports |
| PC Interface | DisplayPort |
| Picture Enhancements | 93% DCI-P3 color gamut, Pixel Shift |
| Width | 74.8 in |
| Depth | 1.3 in |
| Height | 42.5 in |
| Weight | 97 lbs |
| Enclosure Color | Black |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Included Accessories | 2 power cables |
| Compliant Standards | IPX5, CB, FCC, IC, VOC, UL 4200A, SDDPI, CP65 |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Stand by | 0.5 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 20 - 80% |
| Display | |
| LCD Display Technology | VA |
| LED Lifetime | 50000 hours |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Image Aspect Ratio | 16:9 |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| LCD Backlight Technology | E-LED backlight |
| Coating | 25% haze |
| Image Contrast Ratio | 4000:1 |
| Brightness | 500 cd/m² |
| Viewing Angle | 178° |
| Viewing Angle (Vertical) | 178° |
| Backlight Life | 50,000 hour(s) |
| Commercial Features | Security lock, Image Rotation |
| Operation Hours / Days | 24 / 7 |
| Additional Features | OSD Rotation, Over-the-Air Update (OTA) |
| Connections | |
| Connector Type | 2 x HDMI input ¦ DisplayPort input ¦ USB 3.0 ¦ USB 2.0 ¦ Audio output ¦ RS-232 input ¦ RS-232 output ¦ LAN |
| Remote Control | |
| Type | Remote control |
| Audio System | |
| Speaker System | 2 speakers |
| Output Power / Total | 20 Watt |
| Speakers | 2 x main channel speaker - 10 Watt |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 81.1 in |
| Depth (Shipping) | 7.5 in |
| Height (Shipping) | 49.9 in |
| Weight (Shipping) | 136.69 lbs |
| Network & Internet Multimedia | |
| Connectivity | Bluetooth, LAN, Wi-Fi |
| Wi-Fi Protocol | 802.11ac, 802.11b, 802.11g, 802.11n |
| Bluetooth Version | Bluetooth 5.2 |
| Digital TV Tuner | |
| MPEG Profiles and Levels | AV1, H.265, HEVC, VP9, H.264, MPEG4, MPEG2 MP@HL |
| Stands & Mounts | |
| Flat Panel Mount Interface | 600 x 400 mm |
| VESA Compatibility | Yes |
| Media Player | |
| Supported Video Formats | AV1, H.265, VP9, AVS2, H.264, MPEG-4, WMV, AVS, MPEG-2, MPEG-1 |
| USB Port | Yes |
| USB Ports Qty | 2 |
| Configuration | ARM Cortex-A55 Quad-Core - 4 GB - 32 GB - ARM Mali-G52 MP2 |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 8.0 |
