Wireless router - WWAN - Wi-Fi 6 - Dual Band - 4G, 5G
| Main Specifications | |
|---|---|
| Product Description | Pepwave 5G Dongle - wireless router - WWAN - Wi-Fi 6 - 4G, 5G - desktop |
| Device Type | Wireless router - wireless cellular modem |
| Enclosure Type | Desktop |
| Cellular Protocol | LTE, 5G Sub-6 Ghz |
| Generation | 4G, 5G |
| Cellular Band | 5G n2, 5G n5, 5G n7, 5G n12, 5G n13, 5G n14, 5G n25, 5G n26, 5G n29, 5G n30, 5G n38, 5G n41, 5G n48, 5G n66, 5g n70, 5G n71, 5G n77, 5G n78, LTE B2, LTE B4, LTE B5, LTE B7, LTE B12, LTE B13, LTE B14, LTE B17, LTE B25, LTE B26, LTE B29, LTE B30, LTE B38, LTE B41, LTE B42, LTE B43, LTE B48, LTE B66, LTE B71 |
| WAN Ports Qty | 1 |
| Data Link Protocol | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Frequency Band | 2.4 GHz / 5 GHz |
| Features | eSIM support, web-based UI, InControl Cloud Management |
| Power | DC 5 V 2 A |
| Dimensions (WxDxH) | 3.9 in x 2.8 in x 0.7 in |
| Weight | 4.76 oz |
| System Requirements | Windows, Apple MacOS, Linux |
| Localization | North America |
| Manufacturer Warranty | 1-year warranty |
| General | |
| Device Type | Wireless router |
| Enclosure Type | Desktop |
| Connectivity Technology | Wired, wireless |
| Data Link Protocol | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Frequency Band | 2.4 GHz / 5 GHz |
| Features | eSIM support, web-based UI, InControl Cloud Management |
| Compliant Standards | Plug and Play, FCC, RoHS |
| Expansion / Connectivity | |
| Interfaces | Antenna: 4 x SMA ¦ USB: 1 x 24 pin USB-C |
| Expansion Slots | 2 Nano-SIM |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Included Accessories | 4 x cellular antennas |
| Localization | North America |
| Power | |
| Power Device | External power adapter |
| Voltage Required | DC 5 V |
| Electric Current Required | 2 A |
| Software / System Requirements | |
| OS Required | Windows, Apple MacOS, Linux |
| Environmental Parameters | |
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 149 °F |
| Humidity Range Operating | 15 - 95% (non-condensing) |
| Communications | |
| Type | Wireless cellular modem |
| Cellular Protocol | LTE, 5G Sub-6 Ghz |
| Generation | 4G, 5G |
| Cellular Band | 5G n2, 5G n5, 5G n7, 5G n12, 5G n13, 5G n14, 5G n25, 5G n26, 5G n29, 5G n30, 5G n38, 5G n41, 5G n48, 5G n66, 5g n70, 5G n71, 5G n77, 5G n78, LTE B2, LTE B4, LTE B5, LTE B7, LTE B12, LTE B13, LTE B14, LTE B17, LTE B25, LTE B26, LTE B29, LTE B30, LTE B38, LTE B41, LTE B42, LTE B43, LTE B48, LTE B66, LTE B71 |
| Max Transfer Rate | 1.6 Gbps |
| Dimensions & Weight | |
| Width | 3.9 in |
| Depth | 2.8 in |
| Height | 0.7 in |
| Weight | 4.76 oz |
| Antenna | |
| Antenna | External detachable |
| Antenna Qty | 4 |
