Document scanner - Dual CIS - Duplex - 8.5 in x 34.0 in - 600 dpi x 600 dpi - up to 18 ppm (mono) / up to 18 ppm (color) - ADF (20 sheets) - USB 2.0, Wi-Fi(n)
| Main Specifications | |
|---|---|
| Product Description | Brother ADS-1500W - document scanner - desktop - USB 2.0, Wi-Fi(n) |
| Device Type | Document scanner - desktop |
| Interface Type | USB 2.0, Wi-Fi(n) |
| Scanning Sensor Type | Dual CIS |
| Max Supported Document Size | 8.5 in x 34.0 in |
| Input Type | Color |
| Grayscale / Color Depth | 8-bit (256 colors) / 30-bit color |
| Grayscale / Color Depth (External) | 24-bit (16.7 million colors) |
| Optical Resolution | 600 dpi x 600 dpi |
| Interpolated Resolution | 1200 dpi x 1200 dpi |
| Max Document Scan Speed | 18 ppm (mono) / 18 ppm (color) |
| Max Document Size | 8.5 in x 34 in |
| Automatic Duplexing | Yes |
| Supported Document Type | Plain paper, business card, plastic card, post card |
| Document Feeder Type | Automatic |
| Feeder Capacity | 20 sheets |
| Flash Memory | 256 MB |
| Power | AC 100 V (50/60 Hz) |
| System Requirements | Microsoft Windows XP, Microsoft Windows 7, Microsoft Windows Vista, Apple MacOS X 10.7.x, Windows 8, Apple MacOS X 10.6.8, Apple MacOS X 10.8.x |
| Microsoft Certification | Compatible with Windows 7 |
| Dimensions (WxDxH) | 11.2 in x 4.1 in x 32.8 in |
| Weight | 3.51 lbs |
| General | |
| Type | Document scanner - desktop |
| Interface Type | USB 2.0, Wi-Fi(n) |
| Max Supported Document Size | 8.5 in x 34.0 in |
| Memory | |
| Flash Memory | 256 MB |
| Expansion / Connectivity | |
| Interfaces Details | USB 2.0 - Type B ¦ USB - Type A |
| Miscellaneous | |
| Cables Included | 1 x USB cable |
| Compatible with Windows 7 | "Compatible with Windows 7" software and devices carry Microsoft’s assurance that these products have passed tests for compatibility and reliability with 32-bit and 64-bit Windows 7. |
| Media Handling | |
| Max Document Size | 8.5 in x 34 in |
| Supported Document Type | Plain paper, business card, plastic card, post card |
| Supported Document Size Details | ADF - up to 8.5 in x 34.0 in |
| Document Feeder Type | Automatic |
| Feeder Capacity | 20 sheets |
| Power | |
| Voltage Required | AC 100 V (50/60 Hz) |
| Power Consumption Operational (Standby) | 14 watt |
| Power Consumption Stand by | 4 watt |
| Power Consumption Sleep | 1.5 watt |
| Software / System Requirements | |
| OS Required | Microsoft Windows XP, Microsoft Windows 7, Microsoft Windows Vista, Apple MacOS X 10.7.x, Windows 8, Apple MacOS X 10.6.8, Apple MacOS X 10.8.x |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 20 - 80% |
| Scanner | |
| Input Type | Color |
| Grayscale Depth | 8-bit (256 colors) |
| Color Depth | 30-bit color |
| Color Depth (External) | 24-bit (16.7 million colors) |
| Optical Resolution | 600 dpi x 600 dpi |
| Interpolated Resolution | 1200 dpi x 1200 dpi |
| Automatic Duplexing | Yes |
| Scanning Sensor Type | Dual CIS |
| Max Document Scan Speed B/W | 18 ppm |
| Max Document Scan Speed Color | 18 ppm |
| Scanner Speed Details | 9 ppm - black&white - A4 - 600 dpi ¦ 9 ppm - color - A4 - 600 dpi ¦ 18 ipm - duplex - black&white - A4 - 600 dpi ¦ 18 ipm - duplex - color - A4 - 600 dpi ¦ 18 ppm - black&white - A4 - 300 dpi ¦ 18 ppm - color - A4 - 300 dpi ¦ 36 ipm - duplex - black&white - A4 - 300 dpi ¦ 36 ipm - duplex - color - A4 - 300 dpi ¦ 18 ppm - black&white - A4 - 200 dpi ¦ 18 ppm - color - A4 - 200 dpi ¦ 36 ipm - duplex - black&white - A4 - 200 dpi ¦ 36 ipm - duplex - color - A4 - 200 dpi ¦ 18 ppm - black&white - A4 - 150 dpi ¦ 18 ppm - color - A4 - 150 dpi ¦ 36 ipm - duplex - black&white - A4 - 150 dpi ¦ 36 ipm - duplex - color - A4 - 150 dpi |
| Scanner Features | 2.7" touch screen LCD display |
| Scan File Formats | JPEG, PDF |
| Compliant Standards | TWAIN, ISIS, WIA |
| Dimensions & Weight | |
| Width | 11.2 in |
| Depth | 4.1 in |
| Height | 32.8 in |
| Weight | 3.51 lbs |
