Server - tower 1 x Core Ultra 5 235 / up to 5 GHz - RAM 16 GB - SSD 256 GB, HDD 8 TB - Intel Graphics - Gigabit Ethernet - 11 IoT Enterprise 2024 LTSC - monitor: none - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | AXIS Camera Station S1216 Mk II - tower Core Ultra 5 235 3.4 GHz - 16 GB - SSD 256 GB, HDD 8 TB - TAA Compliant |
| Type | Server - tower |
| Localization | Region: United States |
| Processor | 1 x Intel Core Ultra 5 (Series 2) 235 / 3.4 GHz (up to 5 GHz, (14-core) |
| Processor Main Features | 14 Threads |
| Neural Processor Unit (NPU) | Intel AI Boost - up to 13 TOPS |
| Cache Memory | 24 MB |
| Cache Per Processor | 24 MB |
| RAM | 16 GB |
| Hard Drive | SSD 256 GB |
| Hard Drive (2nd) | HDD 8 TB |
| Optical Storage | No optical drive |
| Graphics Controller | Intel Graphics - up to 6 TOPS |
| Networking | 1GbE |
| Power | (50/60 Hz) |
| OS Provided | Windows 11 IoT Enterprise 2024 LTSC |
| Software Included | AXIS Camera Station (16 channels license) |
| Dimensions (WxDxH) | 6.1 in x 11.5 in x 12.8 in |
| Weight | 14.55 lbs |
| TAA Compliant | Yes |
| Manufacturer Warranty | Limited warranty - Next Business Day Onsite Support - 5 years |
| General | |
| Type | Server |
| Product Form Factor | Tower |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Localization | Region: United States |
| Expansion / Connectivity | |
| Interfaces | 1 x headphones/microphone - mini-jack (1 front) ¦ 4 x USB 2.0 - Type A (2 front, 2 rear) ¦ 1 x USB 3.2 Gen 2x2 - Type C (1 in front) ¦ 1 x USB 3.2 Gen 2x1 - Type A (1 front) ¦ 3 x DisplayPort (3 rear) ¦ 1 x USB-C 3.2 Gen 2 - Type C (1 rear) ¦ 3 x USB 3.2 Gen 1x1 - Type A (3 rear) ¦ 1 x LAN - RJ-45 (1 rear) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - Next Business Day Onsite Support - 5 years |
| Miscellaneous | |
| Included Accessories | Power cable |
| Compliant Standards | EN 62623, EN 50564, EN 50563:2011, CNS 15936, EN 55035, EN 55032 Class B, EN 61000-3-2, EN 61000-3-3, FCC Part 15 Subpart B Class B, KS C 9835, KS C 9832 Class B, AS/NZS CISPR 32 Class B, VCCI Class B, CAN/CSA-C22.2 No. 62368-1 Third Edition, IEC/EN 62368-1, KC mark, NOM-019, AS/NZS 62368.1:2022, BSMI, Directive 2011/65/EU, EU RoHS, REACH, Directive 2015/863/EU |
| TAA Compliant | Yes |
| RAM | |
| Installed Size | 16 GB |
| Configuration Features | 2 x 8 GB |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Power | |
| Device Type | Power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Provided | 360 watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 20 - 80% RH (non-condensing) |
| Cache Memory | |
| Installed Size | 24 MB |
| Cache Per Processor | 24 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel Graphics - up to 6 TOPS |
| Video Interfaces | DisplayPort |
| Operating System / Software | |
| OS Provided | Windows 11 IoT Enterprise 2024 LTSC |
| Software | AXIS Camera Station (16 channels license) |
| Hard Drive | |
| Type | SSD |
| Capacity | 1 x 256 GB |
| Dimensions & Weight | |
| Width | 6.1 in |
| Depth | 11.5 in |
| Height | 12.8 in |
| Weight | 14.55 lbs |
| Hard Drive (2nd) | |
| Type | HDD |
| Capacity | 1 x 8 TB |
| Features | RAID ready |
| Processor / Chipset | |
| CPU | Intel Core Ultra 5 (Series 2) 235 |
| Clock Speed | 3.4 GHz (P-core) / 2.9 GHz (E-core) |
| Max Turbo Speed | 5 GHz (P-core) / 4.4 GHz (E-core) |
| Number of Cores | 14-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Processor Main Features | 14 Threads |
| Neural Processor Unit (NPU) | |
| Neural Processor Unit (NPU) | Intel AI Boost |
| NPU Performance Up To (TOPS) | 13 TOPS |
| Total Processor Performance Up To (TOPS) | 27 TOPS |
| AI Datatype Support on NPU | INT8 |
| Sparsity Support | Yes |
| AI Software Frameworks Supported by NPU | DirectML, OpenVINO, WebNN, WindowsML, ONNX RT |
| Windows Studio Effects Support | Yes |
