Network surveillance camera - dome - outdoor - dust resistant / water resistant / shock resistant / wind resistant - color (Day&Night) - 2592 x 1944 - LAN 10/100 - H.264, H.265 - DC 48 V / PoE
| Main Specifications | |
|---|---|
| Product Description | i-PRO WV-U25502-V3L - network surveillance camera - dome |
| Device Type | Network surveillance camera - fixed - dome - outdoor - dust resistant / water resistant / shock resistant / wind resistant |
| Dimensions (WxDxH) | 6.1 in x 6.1 in x 4.1 in |
| Weight | 2.2 lbs |
| Color | I-PRO White |
| Connectivity Technology | Wired |
| Camera | Color - Day&Night |
| Max Resolution | 2592 x 1944 |
| Frame Rate (max) | 30 frames per second |
| Motion Detection | Yes |
| Optical Sensor Type | CMOS - 1/2.8" |
| Minimum Illumination | 0.07 lux - color - F1.6 - 30 IRE - shutter 1/30 sec ¦ 0.1 lux - color - F1.6 - 50 IRE - shutter 1/30 sec ¦ 0.006 lux - color - F1.6 - 50 IRE - shutter 16/30 sec ¦ 0 lux - B&W - F1.6 - 50 IRE - shutter 1/30 sec / infrared LEDs on ¦ 0.04 lux - B&W - F1.6 - 50 IRE - shutter 1/30 sec ¦ 0.003 lux - B&W - F1.6 - 50 IRE - shutter 16/30 sec |
| Focal Length | 3.2 mm - 10.2 mm |
| Focus Adjustment | (min distance 0.8 in) |
| Lens Iris | F/1.6 |
| Panning Range (degree) | -105 to +255 |
| Tilting Range (degree) | -30 to +85 |
| Interfaces | Ethernet 10Base-T/100Base-TX |
| Voltage | DC 48 V / PoE |
| Features | ONVIF (Profile G) support, ONVIF (Profile S) support, ONVIF (Profile T) support, auto ICR, digital noise reduction, Scene Change Detection (SCD), Video Motion Detection (VMD), 8 privacy zones, 90° image rotation, 180° image rotation, 270° image rotation, Variable Bitrate (VBR), Unicast Streaming, Multicast Streaming, Group of Pictures (GOP), Device Certificate GlobalSign pre-installed, user authentication, host authentication, Auto VIQS, up to 14 users, 205.4m detect distance (tele), 43.7m detect distance (wide), 82.1m observe distance (tele), 17.5m observe distance (wide), 41.1 m recognize distance (tele), 8.7 m recognize distance (wide), 20.5m identify distance (tele), 4.4m identify distance (wide), DORI coverage, alarm notifications, e-mail alerts, 120 dB dynamic range |
| Environmental Parameters (operating) | -22 °F - 122 °F; 10 - 100% (non-condensing) relative humidity |
| General | |
| Device Type | Network surveillance camera |
| Form Factor | Dome |
| Connectivity Technology | Wired |
| Width | 6.1 in |
| Depth | 6.1 in |
| Height | 4.1 in |
| Weight | 2.2 lbs |
| Expansion / Connectivity | |
| Ports | LAN/power - RJ-45 ¦ Audio line-in/microphone - 3.5 mm stereo jack |
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| Encryption Algorithm | FIPS 140-3 Level 3 |
| Miscellaneous | |
| Compliant Standards | IEEE 802.1x, IEC 62262 IK10, NDAA, UL 62368-1 Third Edition, cUL, CAN/CSA-C22.2 No. 62368-1-19, IEC 62368-1 Third Edition, FCC Part 15 B Class A, ICES-003 issue 7 Class A, EN55032 Class A, EN55035, IP66, IK10 |
| Color | I-PRO White |
| Power | |
| Power Requirements | DC 48 V / PoE - 200 mA |
| Power Device | 9.6 watt |
| Environmental Parameters | |
| Min Operating Temperature | -22 °F |
| Max Operating Temperature | 122 °F |
| Relative Humidity (operating) | 10 - 100% (non-condensing) |
| Camera | |
| Type | Color - Day&Night - fixed - outdoor - dust resistant / water resistant / shock resistant / wind resistant |
| Digital Video Format | H.264, H.265 |
| Max Digital Video Resolution | 2592 x 1944 |
| Motion Detection | Yes |
| Digital Zoom | 12.8 |
| Minimum Illumination | 0.07 lux - color - F1.6 - 30 IRE - shutter 1/30 sec ¦ 0.1 lux - color - F1.6 - 50 IRE - shutter 1/30 sec ¦ 0.006 lux - color - F1.6 - 50 IRE - shutter 16/30 sec ¦ 0 lux - B&W - F1.6 - 50 IRE - shutter 1/30 sec / infrared LEDs on ¦ 0.04 lux - B&W - F1.6 - 50 IRE - shutter 1/30 sec ¦ 0.003 lux - B&W - F1.6 - 50 IRE - shutter 16/30 sec |
| Infrared LEDs | Yes |
| Video Capture | 2592 x 1944 @ 30 fps ¦ 2560 x 1440 @ 30 fps ¦ 1920 x 1080 @ 30 fps ¦ 1280 x 720 @ 30 fps ¦ 640 x 360 @ 30 fps ¦ 320 x 180 @ 30 fps ¦ 2560 x 1920 @ 30 fps ¦ 1280 x 960 @ 30 fps ¦ 640 x 480 @ 30 fps ¦ 400 x 300 @ 30 fps ¦ 320 x 240 @ 30 fps |
| Supported Image Formats | JPEG |
| Features | ONVIF (Profile G) support, ONVIF (Profile S) support, ONVIF (Profile T) support, auto ICR, digital noise reduction, Scene Change Detection (SCD), Video Motion Detection (VMD), 8 privacy zones, 90° image rotation, 180° image rotation, 270° image rotation, Variable Bitrate (VBR), Unicast Streaming, Multicast Streaming, Group of Pictures (GOP), Device Certificate GlobalSign pre-installed, user authentication, host authentication, Auto VIQS, up to 14 users, 205.4m detect distance (tele), 43.7m detect distance (wide), 82.1m observe distance (tele), 17.5m observe distance (wide), 41.1 m recognize distance (tele), 8.7 m recognize distance (wide), 20.5m identify distance (tele), 4.4m identify distance (wide), DORI coverage, alarm notifications, e-mail alerts, 120 dB dynamic range |
| Lens Construction | |
| Focal Length | 3.2 mm - 10.2 mm |
| Lens Iris | F/1.6 |
| Min Focus Distance | 0.8 in |
| Image Sensor | |
| Type | CMOS 1/2.8" |
| Interfaces | |
| Network Interface | Ethernet 10Base-T/100Base-TX |
| Network Protocols | IPv6, TCP/IP, UDP/IP, HTTP, HTTPS, SMTP, DNS, NTP, SNMP 1, SNMP 2, SNMP 3, DHCPv6, RTP, MLD, ICMP, ARP, DiffServ, MQTT, LLDP, IPv4, RTSP, DHCP, DDNS, UPnP, IGMP, RTCP, SRTP |
| Panning | |
| Range (degree) | -105 to +255 |
| Tilting | |
| Range (degree) | -30 to +85 |
