Network surveillance camera - zoom - bullet - outdoor - dust resistant / water resistant / shock resistant / wind resistant - color (Day&Night) - 2 MP - 1920 x 1080 - motorized - LAN 10/100 - H.265, H.264, MJPEG - DC 48 V / PoE
| Main Specifications | |
|---|---|
| Product Description | i-PRO U-Series WV-U15301-V3L - network surveillance camera - bullet |
| Device Type | Network surveillance camera - zoom - bullet - outdoor - dust resistant / water resistant / shock resistant / wind resistant |
| Dimensions (WxDxH) | 4.4 in x 11.8 in x 4.4 in |
| Weight | 2.2 lbs |
| Color | I-PRO White |
| Connectivity Technology | Wired |
| Camera | Color - Day&Night |
| Optical Zoom | 3.2 x |
| Max Resolution | 1920 x 1080 |
| Frame Rate (max) | 30 frames per second |
| Motion Detection | Yes |
| Optical Sensor Type | CMOS - 1/2.8" - 2 MP |
| Minimum Illumination | 0.05 lux - color - F1.6 - 30 IRE - shutter 1/30 sec ¦ 0.06 lux - color - F1.6 - 50 IRE - shutter 1/30 sec ¦ 0.004 lux - color - F1.6 - 50 IRE - shutter 16/30 sec ¦ 0 lux - B&W - F1.6 - 50 IRE - shutter 1/30 sec ¦ 0.03 lux - B&W - F1.6 - 50 IRE - shutter 1/30 sec ¦ 0.002 lux - B&W - F1.6 - 50 IRE - shutter 16/30 sec |
| Focal Length Control | Motorized zoom |
| Focal Length | 3.2 mm - 10.2 mm |
| Focus Adjustment | Motorized (min distance 0.8 in) |
| Lens Iris | F/1.6 |
| Panning Range (degree) | -180 to +180 |
| Tilting Range (degree) | 0 to 100 |
| Interfaces | Ethernet 10Base-T/100Base-TX |
| Voltage | DC 48 V / PoE |
| Features | Adaptive Black Stretch (ABS), Backlight Compensation (BLC), fog compensation, Highlight Compensation (HLC), Automatic Gain Control (AGC), Video Motion Detection (VMD), Scene Change Detection (SCD), Audio Detection, Iintelligent Video Motion Detection (i-VMD), Privacy Zone, Variable Image Quality on Specified area (VIQS), 270° image rotation, user authentication, digest authentication, host authentication, 802.1x authentication, system log, image transmission log, brute force delay protection, alteration detection, secure boot, signed firmware |
| Environmental Parameters (operating) | -22 °F - 122 °F; 10 - 100% (non-condensing) relative humidity |
| General | |
| Device Type | Network surveillance camera |
| Form Factor | Bullet |
| Connectivity Technology | Wired |
| Width | 4.4 in |
| Depth | 11.8 in |
| Height | 4.4 in |
| Weight | 2.2 lbs |
| Expansion / Connectivity | |
| Ports | LAN/power - RJ-45 |
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| Encryption Algorithm | FIPS 140-3 Level 3 |
| Miscellaneous | |
| Compliant Standards | IEEE 802.3af, IEEE 802.1x, NDAA, UL 62368-1 Third Edition, CAN/CSA-C22.2 No. 62368-1-19, IEC 62368-1 Third Edition, ICES-003 issue 7 Class A, EN55032 Class A, EN55035, FCC Part 15 B Class A, IP66, IEC 60529, UL 50E, NEMA Type 4X, IK10, IEC 62262 |
| Color | I-PRO White |
| Power | |
| Power Requirements | DC 48 V / PoE - 200 mA |
| Power Device | 9.6 watt |
| Software / System Requirements | |
| OS Required | Android, Apple iOS 8.0 or higher |
| Environmental Parameters | |
| Min Operating Temperature | -22 °F |
| Max Operating Temperature | 122 °F |
| Relative Humidity (operating) | 10 - 100% (non-condensing) |
| Camera | |
| Type | Color - Day&Night - zoom - outdoor - dust resistant / water resistant / shock resistant / wind resistant |
| Digital Video Format | H.265, H.264, MJPEG |
| Max Digital Video Resolution | 1920 x 1080 |
| Motion Detection | Yes |
| Digital Zoom | 9.6 |
| Exposure Range | 16/30 sec - 1/10000 sec |
| Minimum Illumination | 0.05 lux - color - F1.6 - 30 IRE - shutter 1/30 sec ¦ 0.06 lux - color - F1.6 - 50 IRE - shutter 1/30 sec ¦ 0.004 lux - color - F1.6 - 50 IRE - shutter 16/30 sec ¦ 0 lux - B&W - F1.6 - 50 IRE - shutter 1/30 sec ¦ 0.03 lux - B&W - F1.6 - 50 IRE - shutter 1/30 sec ¦ 0.002 lux - B&W - F1.6 - 50 IRE - shutter 16/30 sec |
| Infrared LEDs | Yes |
| Infrared Distance | 138 ft |
| Video Capture | 1920 x 1080 @ 25/30 fps ¦ 1280 x 720 @ 25/30 fps ¦ 640 x 360 @ 25/30 fps ¦ 320 x 180 @ 25/30 fps ¦ 1280 x 960 @ 25/30 fps ¦ 640 x 480 @ 25/30 fps ¦ 320 x 240 @ 25/30 fps |
| Supported Image Formats | JPEG |
| Features | Adaptive Black Stretch (ABS), Backlight Compensation (BLC), fog compensation, Highlight Compensation (HLC), Automatic Gain Control (AGC), Video Motion Detection (VMD), Scene Change Detection (SCD), Audio Detection, Iintelligent Video Motion Detection (i-VMD), Privacy Zone, Variable Image Quality on Specified area (VIQS), 270° image rotation, user authentication, digest authentication, host authentication, 802.1x authentication, system log, image transmission log, brute force delay protection, alteration detection, secure boot, signed firmware |
| Lens Construction | |
| Type | Motorized zoom |
| Optical Zoom | 3.2 x |
| Focal Length | 3.2 mm - 10.2 mm |
| Lens Iris | F/1.6 |
| Focus Adjustment | Motorized |
| Min Focus Distance | 0.8 in |
| Horizontal Field of View (degree) | 31 - 114 |
| Vertical Field of View (degree) | 17 - 58 |
| Image Sensor | |
| Type | 2 MP CMOS 1/2.8" |
| Interfaces | |
| Network Interface | Ethernet 10Base-T/100Base-TX |
| Network Protocols | IPv6, TCP/IP, UDP/IP, HTTP, HTTPS, SSL, SMTP, DNS, NTP, SNMP 1, SNMP 2, SNMP 3, DHCPv6, RTP, MLD, ICMP, ARP, DiffServ, FTP, SFTP, LLDP, MQTT, IPv4, RTSP, DHCP, DDNS, UPnP, IGMPv3, SRTP, TLS, RTCP |
| Panning | |
| Range (degree) | -180 to +180 |
| Internet of Things (IoT) | |
| Supported Host Device Platform | Android, iOS |
| Tilting | |
| Range (degree) | 0 to 100 |
