Mini PC Ryzen 7 260 / up to 5.1 GHz - RAM 32 GB - SSD 512 GB - NVMe - Radeon 780M - Gigabit Ethernet, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7) - Win 11 Pro - monitor: none - black
| Main Specifications | |
|---|---|
| Product Description | ASUS ExpertCenter PN54-S1 SYS735PETL0 - mini PC Ryzen 7 260 3.8 GHz - 32 GB - SSD 512 GB |
| Type | Personal computer - mini PC |
| Processor | AMD Ryzen 7 260 / 3.8 GHz (up to 5.1 GHz, (8-core) |
| Cache Memory | 16 MB |
| Cache Per Processor | 16 MB |
| RAM | 32 GB DDR5 SDRAM |
| Hard Drive | SSD 512 GB - PCI Express 4.0 - M.2 2280 - NVM Express (NVMe) |
| Optical Storage | No optical drive |
| Graphics Controller | AMD Radeon 780M |
| Networking | 1GbE, 802.11a, 802.11b/g/n, Wi-Fi 5, 2.5GbE, Wi-Fi 6, Bluetooth, Wi-Fi 7 |
| OS Provided | Windows 11 Pro |
| Color | Black |
| Dimensions (WxDxH) | 5.1 in x 5.1 in x 1.3 in |
| Weight | 19.4 oz |
| Manufacturer Warranty | Limited warranty - 3 years |
| General | |
| Type | Personal computer |
| Product Form Factor | Mini PC |
| Built-in Devices | Fingerprint reader |
| Embedded Security | Trusted Platform Module (TPM) Security Chip |
| Color | Black |
| Expansion / Connectivity | |
| Interfaces | 2 x LAN (2.5Gigabit Ethernet) ¦ 1 x USB 2.0 (1 rear) ¦ 3 x USB 3.2 Gen 2 (2 front, 1 rear) ¦ 1 x USB-C 3.2 Gen 2 (1 front) ¦ 1 x headphones/microphone (1 front) ¦ 1 x HDMI (1 rear) ¦ 2 x DisplayPort 1.4 (2 rear) ¦ Thunderbolt 4/USB4/DisplayPort 2.1 (Power Delivery) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| RAM | |
| Installed Size | 32 GB |
| Technology | DDR5 SDRAM |
| Form Factor | SO-DIMM 262-pin |
| Networking | |
| Ethernet Ports | 2 x 2.5 Gigabit Ethernet |
| Wireless LAN Supported | Yes |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7) |
| Features | Dual stream (2x2) |
| Power | |
| Device Type | Power adapter |
| Power Provided | 120 watt |
| Cache Memory | |
| Installed Size | 16 MB |
| Cache Per Processor | 16 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | AMD Radeon 780M |
| Video Interfaces | HDMI, DisplayPort |
| Operating System / Software | |
| OS Provided | Windows 11 Pro |
| Hard Drive | |
| Type | SSD - M.2 2280 |
| Capacity | 1 x 512 GB |
| Interface Type | PCI Express 4.0 |
| Features | NVM Express (NVMe) |
| Dimensions & Weight | |
| Width | 5.1 in |
| Depth | 5.1 in |
| Height | 1.3 in |
| Weight | 19.4 oz |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 7.4 in |
| Shipping Depth | 6.2 in |
| Shipping Height | 5.3 in |
| Shipping Weight | 3.26 lbs |
| Processor / Chipset | |
| CPU | AMD Ryzen 7 260 |
| Clock Speed | 3.8 GHz |
| Max Turbo Speed | 5.1 GHz |
| Number of Cores | 8-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
