UPS (rack-mountable / external) - AC 100-125 V - 1.8 kW - 2200 VA - 9 Ah - RS-232, USB - output connectors: 7 - 2U - black
| Main Specifications | |
|---|---|
| Product Description | CyberPower Smart App Online UPS Series OL2K2RTHD - UPS - 1.8 kW - 2200 VA |
| Device Type | UPS - rack-mountable / external |
| Rack Size | 2U |
| Weight | 38.58 lbs |
| Input Voltage | AC 100-125 V |
| Output Voltage | AC 100/110/115/120/125 V ± 2% |
| Power Capacity | 1.8 kW / 2200 VA |
| Input Connectors | 1 x power NEMA 5-20P |
| Output connectors | 6 x power NEMA 5-20R ¦ 1 x power NEMA L5-20R |
| Battery | Lead acid - 9 Ah |
| Batteries Qty | 3 |
| Run Time (Up To) | 3.1 min at full load |
| Networking | RS-232, USB |
| Included Accessories | Rack mounting rails, screws, rack mounting ears, handles kit, 12 rubber pads, 12 screw hole dust covers, 8 cage nuts |
| Color | Black |
| System Requirements | Linux, Windows |
| Dimensions (WxDxH) | 17.1 in x 15 in x 3.4 in |
| Environmental Standards | ENERGY STAR |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | UPS - rack-mountable / external |
| Height (Rack Units) | 2U |
| Color | Black |
| Expansion / Connectivity | |
| Interfaces | 1 x management (RS-232) ¦ 1 x management (USB) ¦ 1 x EPO (emergency power off) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | Rack mounting rails, screws, rack mounting ears, handles kit, 12 rubber pads, 12 screw hole dust covers, 8 cage nuts |
| Cables Included | USB cable - external ¦ Serial cable - external ¦ Power cable - integrated - 10 ft |
| Rack Mounting Kit | Included |
| Equipment Protection Value | 400000 US Dollars |
| Features | Tool-less front panel, Upgradeable Firmware, metal housing, double conversion, LCD display, GreenPower UPS Technology, Eco-Mode, hot-swappable batteries, Fast Charge technology, EMI/RFI filtering, generator compatible, converter mode, audible alarm, Battery Equalization Technology, Smart Battery Management (SMB), 20A fuse, cold-start function, internal bypass, built-in maintenance bypass, Human Interface Device (HID) support, LED indicators, rotatable LCD panel |
| Compliant Standards | UL 1778, RoHS, FCC Part 15 A, CSA C22.2 No. 107.3 |
| Networking | |
| Remote Management Interface | RS-232, USB |
| Software / System Requirements | |
| Software Included | PowerPanel Business Edition |
| OS Required | Linux, Windows |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 90% (non-condensing) |
| Battery | |
| Quantity | 3 |
| Technology | Lead acid |
| Voltage Provided | 12 V |
| Capacity | 9 Ah |
| Run Time (Up To) | 10.3 min at half load ¦ 3.1 min at full load |
| Recharge Time | 4 hours |
| Transfer Time | 0 ms |
| Features | Sealed |
| Power Device | |
| UPS Technology | On-line |
| Input Voltage | AC 100-125 V |
| Frequency Provided | 50/60 Hz ± 0.25Hz |
| Frequency Required | 40 - 70 Hz |
| Input Connectors | 1 x power NEMA 5-20P |
| Power Output Connectors Details | 6 x power NEMA 5-20R ¦ 1 x power NEMA L5-20R |
| Output Voltage | AC 100/110/115/120/125 V ± 2% - 50/60 Hz |
| Power Capacity | 1.8 kW / 2200 VA |
| Output Waveform | Sinewave |
| Surge Suppression | Yes |
| Surge Energy Rating | 710 joules |
| Circuit Protection | Circuit breaker |
| Efficiency | 96% Eco mode |
| Power Factor (PF) | 0.82 |
| Total Harmonic Distortion (THD) | 5 % |
| Dimensions & Weight | |
| Width | 17.1 in |
| Depth | 15 in |
| Height | 3.4 in |
| Weight | 38.58 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 22.1 in |
| Shipping Depth | 18.9 in |
| Shipping Height | 9.4 in |
| Shipping Weight | 46.96 lbs |
| Sustainability Information | |
| ENERGY STAR | Yes |
