UPS (rack-mountable) - AC 120 V - 750 Wh - 1000 VA - 1-phase - lithium ion - RJ-45, USB, NFC - output connectors: 6 - 1U - for P/N: SRWALLBRKT2U, SRWALLBRKT4U, SRWALLBRKT6U
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series - UPS - 750 Wh - 1000 VA - Li-Ion |
| Device Type | UPS - rack-mountable |
| Rack Size | 1U |
| Weight | 9.26 lbs |
| Input Wiring | 1-phase |
| Input Voltage | AC 120 V |
| Output Voltage | AC 120 V |
| Power Capacity | 750 Wh / 1000 VA |
| Input Connectors | 1 x power NEMA 5-15P |
| Output connectors | 6 x power NEMA 5-15R (UPS and surge) - 120 V |
| Battery | Lithium ion |
| Run Time (Up To) | 1.5 min at full load |
| Networking | RJ-45, USB, NFC |
| Remote Management Protocol | CLI |
| Dimensions (WxDxH) | 17.2 in x 15.6 in x 1.7 in |
| Environmental Standards | ENERGY STAR |
| Manufacturer Warranty | 5-year warranty |
| Designed For | P/N: SRWALLBRKT2U, SRWALLBRKT4U, SRWALLBRKT6U |
| General | |
| Device Type | UPS - rack-mountable |
| Height (Rack Units) | 1U |
| Expansion / Connectivity | |
| Interfaces | 1 x monitoring - RJ-45 ¦ 1 x console - 24 pin USB-C |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Cables Included | Power cable - integrated - 5 ft |
| Rack Mounting Kit | Included |
| Equipment Protection Value | 250000 US Dollars |
| Features | Overvoltage protection, surge/noise protection, on/off switch, push notifications, two-factor authentication, ABS housing, 15 A circuit breaker, battery backup capability, LED indicators, audible alarm, cold-start function, energy saving green topology, LCD display |
| Compliant Standards | CAN/CSA-C22.2 No. 107.3 (Canada), CEC, CSA (Canada), DOE, FCC Part 15 B, Mexico NOM, RoHS, UL 1778 |
| Networking | |
| Remote Management Interface | RJ-45, USB, NFC |
| Remote Management Protocol | CLI |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 95% RH (non-condensing) |
| Sound Emission | 40 dBA |
| Battery | |
| Technology | Lithium ion |
| Run Time (Up To) | 1.5 min at full load ¦ 8 min at half load |
| Recharge Time | 8 hours |
| Transfer Time | 10 ms |
| Power Device | |
| Input Voltage | AC 120 V |
| Frequency Provided | 50/60 Hz |
| Input Wiring | 1-phase |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x power NEMA 5-15P |
| Power Output Connectors Details | 6 x power NEMA 5-15R (UPS and surge) - 120 V |
| Output Voltage | AC 120 V 50/60 Hz |
| Power Capacity | 750 Wh / 1000 VA |
| Output Waveform | Sinewave |
| Surge Suppression | Yes |
| Surge Energy Rating | 158 Joules |
| Circuit Protection | Circuit breaker |
| Efficiency | 98% at 100% Load |
| Power Factor (PF) | 0.7 |
| Dimensions & Weight | |
| Width | 17.2 in |
| Depth | 15.6 in |
| Height | 1.7 in |
| Weight | 9.26 lbs |
| Compatibility Information | |
| Designed For | P/N: SRWALLBRKT2U, SRWALLBRKT4U, SRWALLBRKT6U |
| Sustainability Information | |
| ENERGY STAR | Yes |
