Hard drive array - 4 TB - 4 bays (SATA-600) - SSD 1 TB x 4 - Thunderbolt 3, USB 3.1 Gen 2 (external)
| Main Specifications | |
|---|---|
| Product Description | Promise Pegasus M4 - hard drive array |
| Device Type | Hard drive array |
| Total Array Capacity | 4 TB |
| Interface | Thunderbolt 3, USB 3.1 Gen 2 |
| Maximum LUNs | 128 |
| Installed Devices / Modules Qty | 4 (installed) / 4 (max) |
| Supported Drives | SATA-600 |
| Built-in Devices | Status LED |
| Storage Controller | RAID (SATA 6Gb/s) - RAID 0, 1, 5, 6, 10, JBOD |
| Hard Drive | 4 x 1 TB SSD SATA 6Gb/s - hot-swap - 2.5" - hot spare |
| OS Required | Apple MacOS, Microsoft Windows |
| Power | AC 100-240 V 50/60 Hz |
| Dimensions (WxDxH) | 5 in x 6.6 in x 4.2 in |
| Weight | 4.19 lbs |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Hard drive array |
| Expansion / Connectivity | |
| Expansion Bays | 4 (total) / 0 (free) x hot-swap - 2.5" |
| Interfaces | 2 x Thunderbolt 3 / USB 3.1 Gen 2 - 24 pin USB-C |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - technical support - 3 years |
| Miscellaneous | |
| Features | Kensington security slot, daisy chaining support |
| Compliant Standards | EMC, FCC, cTUVus, CB, ERP, EuP, RoHS, WEEE |
| RAM | |
| Installed Size | 1 GB |
| Storage | |
| Total Array Capacity | 4 TB |
| HDD Array External Interface | Thunderbolt 3, USB 3.1 Gen 2 |
| Maximum LUNs | 128 |
| Power | |
| Power Device | External power adapter |
| Voltage Required | AC 100-240 V 50/60 Hz |
| Power Provided | 120 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 10 - 95% (non-condensing) |
| Storage Controller | |
| Type | RAID |
| Interface Type | SATA 6Gb/s |
| Data Transfer Rate | 600 MBps |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD |
| System Requirements | |
| OS Required | Apple MacOS, Microsoft Windows |
| Hard Drive | |
| Type | SSD - hot-swap - 2.5" |
| Capacity | 4 x 1 TB |
| Interface Type | SATA 6Gb/s |
| Features | Hot spare |
| Dimensions & Weight | |
| Width | 5 in |
| Depth | 6.6 in |
| Height | 4.2 in |
| Weight | 4.19 lbs |
| Chassis | |
| Built-in Devices | Status LED |
| Installed Devices / Modules Qty | 4 |
| Supported Devices / Modules Qty | 4 |
| Supported Drives | SATA-600 |
