Barebone - mini PC 1 x Core i7 1255U / up to 4.7 GHz - RAM 0 GB - Intel Iris Xe Graphics - IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3, Gigabit Ethernet - eco black
| Main Specifications | |
|---|---|
| Product Description | ASUS Mini PC PL64 BB7-TWVUU - mini PC Core i7 1255U - 0 GB - no HDD |
| Type | PC barebone - mini PC |
| Processor | 1 x Intel Core i7 (12th Gen) 1255U (up to 4.7 GHz, (10-core) |
| Processor Main Features | Intel Smart Cache |
| Cache Memory | 12 MB |
| Cache Per Processor | 12 MB |
| RAM | 0 GB (installed) / 32 GB (max) - DDR4 SDRAM |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Graphics Controller | Intel Iris Xe Graphics |
| Networking | 802.11a, Wi-Fi 5, Wi-Fi 6E, 802.11b/g/n, Bluetooth 5.3, 1GbE |
| OS Provided | No operating system |
| Color | Eco black |
| Dimensions (WxDxH) | 7.9 in x 4.7 in x 1.3 in |
| Weight | 2.2 lbs |
| Environmental Standards | ENERGY STAR Qualified EPEAT Silver |
| Manufacturer Warranty | Limited warranty - 3 years |
| General | |
| Type | PC barebone |
| Product Form Factor | Mini PC |
| Color | Eco black |
| Expansion / Connectivity | |
| Slots | 2 (total) / 2 (free) x M.2 Card - 2280 (for internal storage) |
| Interfaces | 3 x HDMI (3 rear) ¦ 1 x LAN (2.5Gigabit Ethernet) (1 rear) ¦ 1 x LAN (Gigabit Ethernet) (1 rear) ¦ 3 x USB 3.2 Gen 2 (3 in front) ¦ 2 x USB 3.1 Gen 1 (2 side) ¦ 2 x serial - RJ-50 (2 in front) ¦ 1 x headphones/microphone - mini-jack (1 front) ¦ 2 x antenna |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| VESA Mounting Interface | Yes |
| Compliant Standards | MIL-STD 810G, BSMI, CB, FCC, UL, CCC, C-Tick, VCCI |
| RAM | |
| Installed Size | 0 GB (installed) / 32 GB (max) |
| Technology | DDR4 SDRAM |
| Form Factor | SO-DIMM 260-pin |
| Slots | 2 (total) / 2 (empty) |
| Networking | |
| Ethernet Ports | 1 x 2.5 Gigabit Ethernet, 1 x Gigabit Ethernet |
| Wireless LAN Supported | Yes |
| Data Link Protocol | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Bluetooth 5.3, Ethernet, Fast Ethernet, Gigabit Ethernet |
| Power | |
| Device Type | Power adapter |
| Power Provided | 65 watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Sound Emission | 38 dBA |
| Cache Memory | |
| Installed Size | 12 MB |
| Cache Per Processor | 12 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel Iris Xe Graphics |
| Video Interfaces | HDMI |
| Max Monitors Supported | 3 |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Operating System / Software | |
| OS Provided | No operating system |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 7.9 in |
| Depth | 4.7 in |
| Height | 1.3 in |
| Weight | 2.2 lbs |
| Processor / Chipset | |
| CPU | Intel Core i7 (12th Gen) 1255U |
| Max Turbo Speed | 4.7 GHz (P-core) / 3.5 GHz (E-core) |
| Number of Cores | 10-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Processor Main Features | Intel Smart Cache |
| Sustainability Information | |
| EPEAT Compliant | EPEAT Silver |
| ENERGY STAR Certified | Yes |
