Network surveillance camera - dome - indoor - color (Day&Night) - 4 MP - 2592 x 1520 - motorized - audio - USB - GbE - USB - MJPEG, H.264, H.265 - DC 12 V / PoE Plus Class 4
| Main Specifications | |
|---|---|
| Product Description | Hanwha Vision WiseNet P PND-A7082RV - network surveillance camera - dome |
| Device Type | Network surveillance camera - fixed - dome - indoor |
| Audio | Yes: built-in 3 microphone array |
| Dimensions (WxDxH) | 6.3 in x 6.3 in x 4.9 in |
| Weight | 3.42 lbs |
| Color | White, RAL 9003 |
| Connectivity Technology | Wired |
| Camera | Color - Day&Night |
| Optical Zoom | 2 x |
| Max Resolution | 2592 x 1520 |
| Frame Rate (max) | 60 frames per second |
| Motion Detection | Yes |
| Optical Sensor Type | CMOS - 1/1.8" - 4 MP |
| Minimum Illumination | 0.03 lux - color - F1.3 ¦ 0 lux - B&W - infrared LEDs on |
| Focal Length Control | Motorized zoom |
| Focal Length | 4.6 mm - 9.35 mm |
| Focus Adjustment | (min distance 5 ft) |
| Lens Iris | (P-Iris) |
| Panning Range (degree) | 0 to 350 |
| Tilting Range (degree) | -45 to +85 |
| Interfaces | USB, USB, Ethernet 10Base-T/100Base-TX/1000Base-T |
| Voltage | DC 12 V / PoE Plus Class 4 |
| Features | WiseNet 9 chipset, hard-coated dome, WiseStream support, WiseNR II, Ai powered, Extreme Wide Dynamic Range (E-WDR), built-in gyroscope, Handover, dynamic privacy masking, AI Engine Based Analytics, Object Detection, Line Crossing Detection, sound classification, slip detection, fall detection, Backlight Compensation (BLC), Highlight Compensation (HLC), Wide Dynamic Range (WDR), Samsung Super Dynamic Range (SSDR), Digital Image Stabilization (DIS), privacy masking (up to 32 areas), Automatic Tracing White (ATW), Lens Distortion Compensation (LDC), 850nm illuminator, Person Detection, face detection, Vehicle Detection, license plate detection, ONVIF (Profile S) support, ONVIF (Profile T) support, ONVIF (Profile G) support, ONVIF (Profile M) support |
| Environmental Parameters (operating) | -13 °F - 122 °F; 0 - 100% RH (condensing) relative humidity |
| General | |
| Device Type | Network surveillance camera |
| Audio Support | Yes: built-in 3 microphone array |
| Audio Formats | G.711, PCM, G.726, ADPCM, AAC-LC, OPUS |
| Form Factor | Dome |
| Connectivity Technology | Wired |
| Width | 6.3 in |
| Depth | 6.3 in |
| Height | 4.9 in |
| Weight | 3.42 lbs |
| Expansion / Connectivity | |
| Ports | USB-C ¦ Audio line-in/microphone ¦ Audio line out |
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| Encryption Algorithm | FIPS 140-3 Level 3 |
| Miscellaneous | |
| Compliant Standards | IP52, IK10, EAC, cULus, NDAA, FCC, IEC/EN 63000, IEC 60529 IP52, IEC 62262 IK10, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, UL 62368-1, CSA C22.2 No. 62368-1, IEC 62471, FCC 47 CFR Part 15 B Class A, ICES-3(A)/NMB-3(A), CE/UKCA, EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3, CISPR 32 Class A, AS/NZS CISPR 32 Class A, KS C 9832 Class A, KS C 9835, VCCI, RCM |
| Color | White, RAL 9003 |
| Power | |
| Power Requirements | DC 12 V / PoE Plus Class 4 |
| Environmental Parameters | |
| Min Operating Temperature | -13 °F |
| Max Operating Temperature | 122 °F |
| Relative Humidity (operating) | 0 - 100% RH (condensing) |
| Camera | |
| Type | Color - Day&Night - fixed - indoor |
| Digital Video Format | MJPEG, H.264, H.265 |
| Max Digital Video Resolution | 2592 x 1520 |
| Motion Detection | Yes |
| Exposure Range | 2 sec - 1/30000 sec |
| Minimum Illumination | 0.03 lux - color - F1.3 ¦ 0 lux - B&W - infrared LEDs on |
| Infrared LEDs | Yes |
| Infrared Distance | 197 ft |
| Digital Video Capture Resolution | 2592 x 1520, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 640 x 480, 640 x 360, 320 x 240, 320 x 180 |
| Frame Rate (max) | 60 frames per second |
| RAM | 4 GB |
| Flash Memory | 8 GB |
| Features | WiseNet 9 chipset, hard-coated dome, WiseStream support, WiseNR II, Ai powered, Extreme Wide Dynamic Range (E-WDR), built-in gyroscope, Handover, dynamic privacy masking, AI Engine Based Analytics, Object Detection, Line Crossing Detection, sound classification, slip detection, fall detection, Backlight Compensation (BLC), Highlight Compensation (HLC), Wide Dynamic Range (WDR), Samsung Super Dynamic Range (SSDR), Digital Image Stabilization (DIS), privacy masking (up to 32 areas), Automatic Tracing White (ATW), Lens Distortion Compensation (LDC), 850nm illuminator, Person Detection, face detection, Vehicle Detection, license plate detection, ONVIF (Profile S) support, ONVIF (Profile T) support, ONVIF (Profile G) support, ONVIF (Profile M) support |
| Lens Construction | |
| Type | Motorized zoom |
| Optical Zoom | 2 x |
| Focal Length | 4.6 mm - 9.35 mm |
| Lens Iris | (P-Iris) |
| Min Focus Distance | 5 ft |
| Horizontal Field of View (degree) | 47 - 105 |
| Vertical Field of View (degree) | 27 - 58 |
| Diagonal Field of View (degree) | 55 - 128 |
| Image Sensor | |
| Type | 4 MP CMOS 1/1.8" |
| Interfaces | |
| Video | USB |
| Network Interface | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP, RTCP, RTSP, NTP, HTTP, HTTPS, SSL, TLS, DHCP, FTP, SMTP, ICMP, SNMP 1, SNMP 2c, SNMP 3, ARP, DNS, DDNS, QOS, PIM-SM, UPnP, LLDP, Bonjour, EAP |
| Computer Interface | USB |
| Alarm Inputs Qty | 1 |
| Alarm Outputs Qty | 1 |
| Panning | |
| Range (degree) | 0 to 350 |
| Tilting | |
| Range (degree) | -45 to +85 |
