AI PC - tower gaming - Core Ultra 9 285K / up to 5.6 GHz - RAM 64 GB - SSD 2 TB - NVMe - GeForce RTX 5090 - Gigabit Ethernet, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 - Win 11 Pro - monitor: none - keyboard: English - storm gray
| Main Specifications | |
|---|---|
| Product Description | Lenovo Legion T7 34IAS10 - tower - AI PC - Core Ultra 9 285K - 64 GB - SSD 2 TB - English |
| Type | Personal computer - tower - AI PC |
| Localization | Language: English / region: United States |
| Processor | Intel Core Ultra 9 (Series 2) 285K (up to 5.6 GHz, (24-core) |
| Neural Processor Unit (NPU) | Intel AI Boost - up to 13 TOPS |
| Cache Memory | 40 MB |
| Cache Per Processor | 40 MB |
| RAM | 64 GB (installed) / 128 GB (max) - DDR5 SDRAM |
| Hard Drive | SSD 2 TB - PCI Express 4.0 x4 - M.2 2280 - NVM Express (NVMe) |
| Optical Storage | No optical drive |
| Multi-GPU Configuration | 1 single GPU card / integrated GPU |
| Graphics Controller | NVIDIA GeForce RTX 5090 / Intel Graphics |
| Video Memory | GDDR7 SDRAM |
| Gaming | Yes |
| Networking | 1GbE, 802.11a, 802.11b/g/n, Wi-Fi 5, 2.5GbE, Wi-Fi 6E, Bluetooth 5.3 |
| Keyboard | English |
| Power | (50/60 Hz) |
| OS Provided | Windows 11 Pro |
| Color | Storm gray |
| Dimensions (WxDxH) | 8.3 in x 17.6 in x 19.3 in |
| Weight | 39.68 lbs |
| General | |
| Type | Personal computer |
| AI Level | AI PC |
| Product Form Factor | Tower |
| Built-in Devices | 1 x rear fan, transparent side cover, 2 x top ARGB fans, internal ambient lighting, 3 x 120 mm RGB fans, Legion lighting |
| Gaming | Yes |
| Embedded Security | Firmware Trusted Platform Module (TPM 2.0) Security Chip |
| Color | Storm gray |
| Localization | Language: English / region: United States |
| Expansion / Connectivity | |
| Slots | 4 (total) / 3 (free) x M.2 Card (for SSD) ¦ 1 PCIe 5.0 x16 ¦ 1 PCIe 4.0 x16 (x4 mode) ¦ 1 PCIe 3.0 x1 |
| Interfaces | 1 x USB-C 3.2 Gen 2 (1 top) ¦ 5 x USB 3.2 Gen 1 (1 top, 4 rear) ¦ 4 x USB 2.0 (2 top, 2 rear) ¦ 1 x headphones/microphone (1 top) ¦ 1 x Thunderbolt 4/USB4/DisplayPort 2.1 (1 rear) (Power Delivery 3.1) ¦ 1 x USB 3.2 Gen 2 (1 rear) ¦ 1 x DisplayPort 1.4 (1 rear) ¦ 1 x LAN (2.5Gigabit Ethernet) (1 rear) ¦ 6 x audio connector (6 rear) |
| Miscellaneous | |
| Gaming | Yes |
| Included Accessories | PCH heatsink, VRM heatsink |
| Compliant Standards | RoHS, Energy-Related Products (ErP) Lot 3 |
| RAM | |
| Installed Size | 64 GB (installed) / 128 GB (max) |
| Technology | DDR5 SDRAM |
| Effective Memory Speed | 5600 MT/s |
| Rated Memory Speed | 5600 MT/s |
| Form Factor | DIMM 288-pin |
| Slots | 4 (total) / 2 (empty) |
| Features | Dual channel memory architecture |
| Configuration Features | 2 x 32 GB |
| Networking | |
| Ethernet Controller | Realtek RTL8125BG |
| Wireless LAN Supported | Yes |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 |
| Features | Dual stream (2x2) |
| Power | |
| Device Type | Power supply |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Provided | 1200 watt |
| Efficiency | 90% |
| Cache Memory | |
| Installed Size | 40 MB |
| Cache Per Processor | 40 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Multi-GPU Configuration | 1 single GPU card / integrated GPU |
| Graphics Processor | NVIDIA GeForce RTX 5090 / Intel Graphics |
| Video Memory | GDDR7 SDRAM |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Operating System / Software | |
| OS Provided | Windows 11 Pro English |
| Hard Drive | |
| Type | SSD - M.2 2280 |
| Capacity | 1 x 2 TB |
| Interface Type | PCI Express 4.0 x4 |
| Features | NVM Express (NVMe) |
| Input Device | |
| Type | Mouse, keyboard |
| Dimensions & Weight | |
| Width | 8.3 in |
| Depth | 17.6 in |
| Height | 19.3 in |
| Weight | 39.68 lbs |
| Keyboard | |
| Keyboard Name | Lenovo Calliope Keyboard |
| Interface | USB |
| Localization & Layout | English |
| Mouse | |
| Mouse Name | Lenovo Calliope Mouse |
| Interface | USB |
| Processor / Chipset | |
| CPU | Intel Core Ultra 9 (Series 2) 285K |
| Max Turbo Speed | 5.6 GHz |
| Number of Cores | 24-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Chipset Type | Intel Z890 |
| Neural Processor Unit (NPU) | |
| Neural Processor Unit (NPU) | Intel AI Boost |
| NPU Performance Up To (TOPS) | 13 TOPS |
| Total Processor Performance Up To (TOPS) | 36 TOPS |
| AI Datatype Support on NPU | INT8 |
| Sparsity Support | Yes |
| AI Software Frameworks Supported by NPU | DirectML, OpenVINO, WebNN, WindowsML, ONNX RT |
| Windows Studio Effects Support | Yes |
