KVM / audio / USB extender - receiver - HDMI - over CAT 6/7 - USB - up to 394 ft
| Main Specifications | |
|---|---|
| Product Description | SIIG - KVM / audio / USB extender - HDMI |
| Device Type | KVM / audio / USB extender (receiver) - USB |
| Form Factor | External |
| Data Transfer Rate | 10.2 Gbps |
| Data Link Protocol | HDMI |
| Transmission Medium | CAT 6/7 |
| Max Transfer Distance | 394 ft |
| Power | AC 100-240 V |
| Dimensions (WxDxH) | 4.1 in x 4.4 in x 0.9 in |
| Weight | 7.51 oz |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | KVM / audio / USB extender (receiver) |
| Form Factor | External |
| Color | Black |
| Expansion / Connectivity | |
| Interfaces | 1 x HDMI (input) - 19 pin HDMI Type A female ¦ 2 x USB - Type A female ¦ 1 x network - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Compliant Standards | Plug and Play, FCC, RoHS, UL E470034 Level VI |
| Networking | |
| Connectivity Technology | Wired |
| Data Link Protocol | HDMI |
| Data Transfer Rate | 10.2 Gbps |
| Keyboard / Mouse Interface | USB |
| Max Resolution | 4K @ 30 Hz |
| Max Video Bandwidth | 340 MHz |
| Max Transfer Distance | 394 ft |
| Status Indicators | Power, KVM |
| Features | Low-latency signal transmission, metal housing |
| Compliant Standards | HDCP 1.4 |
| Power | |
| Power Device | External power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 5 - 90% RH (non-condensing) |
| Dimensions & Weight | |
| Width | 4.1 in |
| Depth | 4.4 in |
| Height | 0.9 in |
| Weight | 7.51 oz |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 8.1 in |
| Shipping Depth | 7.4 in |
| Shipping Height | 2.2 in |
| Shipping Weight | 16.33 oz |
