Essential Series LED display unit - digital signage 480 x 270 per unit
| Main Specifications | |
|---|---|
| Product Description | Planar DirectLight DL Essential 1.2 Essential Series LED display unit - for digital signage |
| Product Type | LED display unit |
| Commercial Use | Yes - digital signage |
| Frame Rate & Enhancement Technology | 3840 Hz Refresh Rate |
| TV Tuner | No tuner |
| Commercial Features | ColorLight controller |
| Video Wall Display Unit | 480 x 270 |
| Included Accessories | Remote control, Planar WallDirector Video controller |
| Voltage | AC 100-240 V |
| Dimensions (WxDxH) - cabinet | 23.6 in x 1.6 in x 13.3 in |
| Weight | 9.7 lbs |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED display unit |
| Commercial Use | Yes - digital signage |
| Series | Essential Series |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Dimensions | Cabinet |
| Width | 23.6 in |
| Depth | 1.6 in |
| Height | 13.3 in |
| Weight | 9.7 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | Planar WallDirector Video controller |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V |
| Video Wall Display Unit Power Consumption (Max) | 593 W |
| Video Wall Display Unit Power Consumption (Typical) | 127 W |
| Environmental Parameters | |
| Min Operating Temperature | 14 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 80% |
| Display | |
| Frame Rate & Enhancement Technology | 3840 Hz Refresh Rate |
| Color Temperature | 3000 - 10000K |
| Image Contrast Ratio | 30000:1 |
| Brightness | 1000 cd/m² |
| Viewing Angle | 170° |
| Viewing Angle (Vertical) | 150° |
| Commercial Features | ColorLight controller |
| Remote Control | |
| Type | Remote control |
| Stands & Mounts | |
| Wall Mount Included | Yes |
| Video Wall Display Unit | |
| Pixel Pitch | 1.25 mm |
| Pixels Per Panel | 129600 |
| Resolution | 480 x 270 |
| LED Lifetime | 100000 hours |
| Maintenance | Front |
| Modules Configuration (Per Cabinet) | 4x2 |
