Video/audio extender - HDMI - up to 33 ft
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series - video/audio extender - HDMI |
| Device Type | Video/audio extender |
| Form Factor | External |
| Data Link Protocol | HDMI |
| Max Transfer Distance | 33 ft |
| Power | AC 100-240 V |
| Dimensions (WxDxH) | 8.5 in x 3.6 in x 0.7 in |
| Weight | 19.05 oz |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Video/audio extender |
| Form Factor | External |
| Color | Black |
| Expansion / Connectivity | |
| Interfaces | 1 x micro-USB (firmware update) ¦ 4 x HDMI - 19 pin HDMI Type A female ¦ 2 x HDMI - 19 pin HDMI Type A female ¦ 1 x audio - phone 3.5 mm female ¦ 1 x TOSLINK female ¦ 1 x micro-USB female |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | Remote control, rubber feet |
| Cables Included | 1 x USB-A to Micro-USB Type B cable - 5 ft |
| Mounting Kit | Included |
| Compliant Standards | Plug and Play, EDID compatible, RoHS, FCC, PSE Mark, TUV, UKCA, UL, WEEE, cUL, CAN/CSA-C22.2 No. 62368-1, EN 55032, EN 55035, REACH, UL 62368-1 |
| Networking | |
| Connectivity Technology | Wired |
| Data Link Protocol | HDMI |
| Max Resolution | 3840 x 2160 @ 30 Hz |
| Max Transfer Distance | 33 ft |
| Status Indicators | Output, power |
| Features | 4:4:4 chroma subsampling support, PIP function, 12-bit Deep Color support, seamless switching, Dolby Digital support, DTS support, LPCM support, scaling function, multi-view presentation, 10.2 Gbps bandwidth, nickel plated connector |
| Compliant Standards | HDCP 1.4 |
| Power | |
| Power Device | External power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 10 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 158 °F |
| Humidity Range Operating | 5 - 90% RH (non-condensing) |
| Dimensions & Weight | |
| Width | 8.5 in |
| Depth | 3.6 in |
| Height | 0.7 in |
| Weight | 19.05 oz |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 11.5 in |
| Shipping Depth | 9.4 in |
| Shipping Height | 2.2 in |
| Shipping Weight | 32.48 oz |
