KVM / audio / USB switch - 4 x KVM / audio / USB - 1 local user - desktop - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | Startech - KVM / audio / USB switch - 4 ports - TAA Compliant |
| Device Type | KVM / audio / USB switch - 4 ports |
| Subtype | KVM |
| Ports | 4 x KVM / audio / USB |
| KVM Users Qty | 1 local user |
| Features | CAC reader support, metal housing, anti-tampering protection, push button, NIAP Protection Profile 4.0, quad display support, 2 channel analog audio, 4K60Hz support |
| Compliant Standards | USB 2.0 |
| Dimensions (WxDxH) | 12.6 in x 6.7 in x 1.7 in |
| Weight | 4.19 lbs |
| Color | Black |
| TAA Compliant | Yes |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | KVM / audio / USB switch - 4 ports |
| Enclosure Type | Desktop |
| Subtype | KVM |
| Ports | 4 x KVM / audio / USB |
| KVM Local Users Qty | 1 local user |
| Keyboard / Mouse Interface | USB |
| Max Resolution | 3840 x 2160 @ 60 Hz |
| Features | CAC reader support, metal housing, anti-tampering protection, push button, NIAP Protection Profile 4.0, quad display support, 2 channel analog audio, 4K60Hz support |
| Compliant Standards | USB 2.0 |
| Status Indicators | Port status, select, video, CAC |
| Expansion / Connectivity | |
| Interfaces | 3 x USB 2.0 Type A console ¦ 1 x DisplayPort output console ¦ 1 x HDMI output console ¦ 1 x audio phone stereo 3.5 mm console ¦ 4 x DisplayPort input host ¦ 4 x HDMI input host ¦ 4 x audio phone stereo 3.5 mm host ¦ 8 x USB 2.0 input Type B host |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Color | Black |
| Compliant Standards | FCC, RoHS, WEEE, NIAP |
| TAA Compliant | Yes |
| Power | |
| Power Device | External power adapter |
| Power Provided | DC 12 V |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 80% RH (non-condensing) |
| Min Storage Temperature | -4 °F |
| Max Storage Temperature | 140 °F |
| Dimensions & Weight | |
| Width | 12.6 in |
| Depth | 6.7 in |
| Height | 1.7 in |
| Weight | 4.19 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 16.5 in |
| Shipping Depth | 11.5 in |
| Shipping Height | 4.5 in |
| Shipping Weight | 4.63 lbs |
