Docking station - Thunderbolt 5 - 3 x Thunderbolt 5 - 1GbE - 90 Watt
| Main Specifications | |
|---|---|
| Product Description | OWC - docking station - Thunderbolt 5 - 3 x Thunderbolt 5 - 1GbE |
| Product Type | Docking station |
| Docking Interface | Thunderbolt 5 |
| Video Interfaces | 3 x Thunderbolt 5 |
| Dimensions (WxDxH) | 4.3 in x 8.3 in x 1.4 in |
| Weight | 31.74 oz |
| Color | Black |
| Networking | Gigabit Ethernet |
| Power | Power adapter AC 100-240 V (50 - 60 Hz) 90 Watt Power Provided (19 V) |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Product Type | Docking station |
| Width | 4.3 in |
| Depth | 8.3 in |
| Height | 1.4 in |
| Weight | 31.74 oz |
| Enclosure Color | Black |
| Expansion / Connectivity | |
| Interfaces | 1 x Thunderbolt 5 host - Thunderbolt 5 ¦ 3 x USB 3.2 - 9 pin USB Type A ¦ 1 x USB-C 3.2 - 24 pin USB-C ¦ 2 x network - 10Gb Ethernet - RJ-45 ¦ 1 x network - 2.5G Gigabit Ethernet - RJ-45 ¦ 3 x Thunderbolt 5 - Thunderbolt 5 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Cables Included | 1 x Thunderbolt 3 / USB-C cable |
| Features | Aluminum housing, security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| Compliant Standards | FCC, RCM, VCCI, UKCA, IC, Thunderbolt, RoHS |
| Networking | |
| Data Link Protocol | Gigabit Ethernet |
| Power | |
| Power Device | Power adapter |
| Voltage Required | AC 100-240 V (50 - 60 Hz) |
| Power Provided | 90 Watt |
| Voltage Provided | 19 V |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 86 °F |
| Video | |
| Max Resolution Details | 8K - 60 Hz (Triple Display) ¦ 8K - 120 Hz (Dual Display) ¦ 8K - 144 Hz (Single Display) |
| System Requirements | |
| OS Required | Apple macOS Sequoia 15.x, Apple macOS Sonoma 14.x, Apple macOS Tahoe 26.x, Windows 11, Linux |
