400 Premium Coverage Series - speaker - 75 Watt - 2-way - coaxial (grille color - white, RAL 9003)
| Main Specifications | |
|---|---|
| Product Description | JBL Professional Control 447LP - speaker |
| Product Type | 400 Premium Coverage Series - speaker |
| Speaker Type | Coaxial - 2-way - passive |
| Continuous Power | 75 Watt |
| Peak Power | 300 Watt |
| Nominal Impedance | 8 Ohm |
| Integrated Transformer | 70V/100V operation |
| Dimensions (WxDxH) | 6.1 in |
| Dimensions - Diameter | 12.4 in |
| Weight | 11.24 lbs |
| General | |
| Product Type | Speaker |
| Features | Radiation Boundary Integrator (RBI) |
| Enclosure Material | PC/ABS, powder-coated steel |
| Design Features | Low-profile grille, paintable |
| Grille Color | White, RAL 9003 |
| Miscellaneous | |
| Compliant Standards | IP33, IEC 60529, EN 60529, Directive 2011/65/EU, Directive 2015/863/EU, UL 2043, NFPA 90A, NFPA 70, CSA C22.2 No. 205, RoHS, UL 1480A |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Dimensions & Weight | |
| Diameter | 12.4 in |
| Height | 6.1 in |
| Weight | 11.24 lbs |
| Speaker System | |
| Series | 400 Premium Coverage Series |
| Speaker Type | Coaxial - 2-way - passive |
| Continuous Power | 75 Watt |
| Peak Power | 300 Watt |
| Frequency Response (-10dB) | 65 - 20000 Hz |
| Nominal Impedance | 8 Ohm |
| Max Output Level (Max SPL) | 117.5 dB |
| Sensitivity | 91 dB (1W@1m) |
| Integrated Transformer | 70V/100V operation |
| Coverage | 120° conical |
| Recommended Placing | In-ceiling mounted |
| Detachable Grilles | Yes |
| Speaker System Details | |
| Driver Details | Speaker: woofer driver - 6.5" - treated paper cone ¦ Speaker: tweeter driver - 1" - neodymium - Soft Dome |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 34.88 lbs |
| Cutout & Mounting Dimensions | |
| Diameter | 11.1 in |
