Door access control expansion board - wired - Wiegand
| Main Specifications | |
|---|---|
| Product Description | Hanwha Vision NOP-RI2MS - door access control expansion board |
| Product Type | Door access control expansion board |
| Intended For | Door access controller |
| Integrated Components | Fuse |
| Power Source | Power adapter |
| Connectivity | Wired - Wiegand |
| Dimensions (WxDxH) | 5.4 in x 0.9 in x 2.8 in |
| General | |
| Product Type | Door access control expansion board |
| Intended For | Door access controller |
| Integrated Components | Fuse |
| Power Source | Power adapter |
| Connectivity Technology | Wired - Wiegand |
| Interfaces Details | 6 x alarm input ¦ 4 x relay output ¦ 2 x Wiegand/OSDP reader ¦ Serial (RS-485) ¦ 2 x unsupervised input ¦ 6 x supervised input |
| Features | 2 door access, LED indicators downstream, Open Supervised Device Protocol (OSDP), secure boot, built-in DIP switch |
| Miscellaneous | |
| Encryption Algorithm | 128-bit AES, 256-bit AES, 256-bit SHA |
| Voltage Required | DC 12 V |
| Compliant Standards | FCC, cULus, cRUus, UL 294, UL 294B, UL 1076, ULC, FCC Part 15 A, RoHS |
| Environmental Parameters | |
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 176 °F |
| Dimensions & Weight | |
| Width | 5.4 in |
| Depth | 0.9 in |
| Height | 2.8 in |
| Weight | 9.88 oz |
