Premium - kiosk 1 5430 - RAM 8 GB 128 GB - Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 LE, NFC - monitor: none
| Main Specifications | |
|---|---|
| Product Description | Zebra ZEC500 - Premium - kiosk 5430 2.1 GHz - 8 GB 128 GB |
| Type | Kiosk - kiosk |
| Processor | 1 x Qualcomm 5430 / 2.1 GHz (8-core) |
| RAM | 8 GB |
| Hard Drive | 128 GB |
| Optical Storage | No optical drive |
| Card Reader | Yes |
| Networking | 1GbE, 802.11a, 802.11b/g/n, Wi-Fi 5, Wi-Fi 6E, Bluetooth 5.3 LE, NFC |
| Dimensions (WxDxH) | 4.7 in x 4.7 in x 1.1 in |
| Weight | 10.93 oz |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | Limited warranty - 1 year |
| General | |
| Type | Kiosk |
| Product Form Factor | Kiosk |
| Expansion / Connectivity | |
| Interfaces | 1 x HDMI ¦ 1 x USB-C 3.2 Gen 2/DisplayPort 1.4 (Power Delivery) ¦ 3 x USB 3.2 ¦ 1 x LAN (Gigabit Ethernet) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| VESA Mounting Interface | VESA, 75 x 75 mm |
| Compliant Standards | IP54, IEC 60529, IEC 60721-3-3, IEC 60068-2-5, ISO 14443 type A, ISO 14443 type B, ISO 15693, FeliCa, MIFARE, WPA3, WPA, OWE, WEP, RoHS 2011/65/EU Amendment 2015/863, REACH SVHC 1907/2006/EC:2022-06-10 |
| RAM | |
| Installed Size | 8 GB |
| Networking | |
| Wireless LAN Supported | Yes |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 LE, NFC |
| Remote Management Protocol | IPv4, IPv6 |
| Features | Power-over-Ethernet (POE), MU-MIMO Support |
| Power | |
| Device Type | Power adapter |
| Power Provided | 60 watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Hard Drive | |
| Capacity | 1 x 128 GB |
| Dimensions & Weight | |
| Width | 4.7 in |
| Depth | 4.7 in |
| Height | 1.1 in |
| Weight | 10.93 oz |
| Card Reader | |
| Type | Card reader |
| Supported Flash Memory Cards | microSD |
| Processor / Chipset | |
| CPU | Qualcomm 5430 |
| Clock Speed | 2.1 GHz |
| Number of Cores | 8-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 8.0 |
