86" Diagonal Class LED-backlit LCD display - interactive - with touchscreen (multi touch) / 8-microphone array / optional slot-in PC capability - 4K UHD (2160p) 3840 x 2160 - Direct LED - B2B - with ViewSonic VB-WIFI-005 Adapter
| Main Specifications | |
|---|---|
| Product Description | ViewSonic ViewBoard IFP8663 86" LED-backlit LCD display - 4K - for interactive communication |
| Product Type | LED-backlit LCD flat panel display with touchscreen (multi touch) / 8-microphone array / optional slot-in PC capability |
| Diagonal Class | 86" |
| Commercial Use | Yes - interactive |
| Bundled with | ViewSonic VB-WIFI-005 Adapter |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| Video Interface | HDMI |
| HDMI Ports Qty | 4 ports |
| Connectivity | Wi-Fi, LAN, Bluetooth |
| PC Interface | DisplayPort, USB-C |
| LCD Backlight Technology | Direct LED |
| Image Aspect Ratio | 16:9 |
| TV Tuner | No tuner |
| Speaker System | 2 speakers, subwoofer |
| Storage Capacity | 128 GB eMMC |
| USB | Yes |
| Included Accessories | Remote control, camera plate, 5 clamps, 8 x screws, RS232 adapter, 2 x stylus |
| Voltage | AC 100-240 V |
| Power Consumption Stand by | 0.5 watt |
| Pricing Type | B2B |
| Environmental Standards | ENERGY STAR Qualified, EPEAT Gold |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Diagonal Class | 86" |
| Commercial Use | Yes - interactive |
| Bundled with | ViewSonic VB-WIFI-005 Adapter |
| Combined With | Touchscreen (multi touch) / 8-microphone array / optional slot-in PC capability |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI |
| HDMI Ports Qty | 4 ports |
| PC Interface | DisplayPort, USB-C |
| Pricing Type | B2B |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years - on-site ¦ Limited warranty - backlight - 3 years |
| Miscellaneous | |
| Included Accessories | Camera plate, 5 clamps, 8 x screws, RS232 adapter, 2 x stylus |
| Cables Included | USB-C cable - 6 ft ¦ Touch cable - 10 ft ¦ HDMI cable - 10 ft |
| Compliant Standards | FCC, RoHS, cTUVus, CEC, Enterprise Device Licensing Agreement (EDLA) certified |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V |
| Power Consumption Stand by | 0.5 watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 80% (non-condensing) |
| Display | |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Image Aspect Ratio | 16:9 |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| LCD Backlight Technology | Direct LED |
| Coating | Anti-glare, 9H Hard, 3 mm glass, anti-fingerprint, anti-bacterial |
| Image Contrast Ratio | 1200:1 |
| Dynamic Contrast Ratio | 5000:1 |
| Brightness | 450 cd/m² |
| Viewing Angle | 178° |
| Viewing Angle (Vertical) | 178° |
| Touchpoints Qty | 50 |
| Response Time | 6.5 ms |
| Backlight Life | 50,000 hours |
| Operation Hours / Days | 24 / 7 |
| Additional Features | Open Pluggable Specification slot, Projected Capacitive Technology (PCAP), 24/7 operation time, ?10ms touch response time |
| Connections | |
| Connector Type | 4 x HDMI input ¦ HDMI output ¦ DisplayPort input ¦ 3 x USB ¦ 5 x USB ¦ 4 x USB-C with 100W Power Delivery ¦ 2 x LAN ¦ RS-232 ¦ Audio input ¦ Microphone input ¦ SPDIF output |
| Remote Control | |
| Type | Remote control |
| Battery Form Factor | AAA type |
| Battery Included | Yes |
| Audio System | |
| Speaker System | 2 speakers, subwoofer |
| Output Power / Total | 60 watt |
| Additional Features | Built-in 8-array microphone |
| Speakers | 2 x main channel speaker - 20 watt ¦ 1 x subwoofer - 20 watt |
| Network & Internet Multimedia | |
| Connectivity | Wi-Fi, LAN, Bluetooth |
| LAN Protocol | Gigabit Ethernet |
| Wi-Fi Protocol | 802.11ax (Wi-Fi 6E) |
| Bluetooth Version | Bluetooth 5.2 |
| Stands & Mounts | |
| Flat Panel Mount Interface | 800 x 600 mm |
| VESA Compatibility | Yes |
| Media Player | |
| USB Port | Yes |
| Configuration | Rockchip RK3576 - 16 GB - 128 GB eMMC |
| Sustainability Information | |
| EPEAT Compliant | EPEAT Gold |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 8.0 |
